108 7: Annotating Items
3. From the Annotations menu, choose Line Width, and then choose
one of the line width options. The checkmark indicates the currently
selected option.
The selected freehand annotation becomes the new width. Other
freehand annotations already on the page will not be affected. The
line width with the checkmark also determines the line width of any
new annotations that you draw.
You can also change the color of a freehand annotation using the
Color command. For more information, see "Fine-Tuning
Annotations" on page 111.
D L
RAWING INES AND
Use the Arrow tool to add lines and arrows to an item. This is a
convenient way to point to important details or to connect an annotation
to an area in an item.
To add lines and arrows:
1. In Page View, click the Arrow tool on the Annotation Tool Bar. The
cursor changes to a crosshair.
2. Drag the mouse to create an arrow.
To change the line width or arrowheads:
1. In Page View, click the Pointer tool on the Annotation Tool Bar.
2. Select the line or arrow. A handle appears at each end.
A
RROWS
