Chapter 4 Bringing up a New Cisco CRS-1 Router
Figure 4-1
PL0 PL1 PL2 PL3
PL8 PL9

Powering On a Single-Chassis System for the First Time

To power on a Cisco CRS-1 router for the first time, perform the following procedure.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
Single-Chassis System
PLIM side of chassis
A0 A1 A2
B0 B1 B2
PL4 PL5 PL6 PL7
PL PL PL PL PL
10 11 12 13 14
Power on the router.
Identify the primary RP.
Connect a terminal to the Console port of the primary RP.
Enter the initial configuration as prompted in the Setup mode.
Enter the optional configuration, as required.
Verify the system.
AM0
AM1
7
PL
15
15 14 13 12
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Bringing Up a Single-Chassis System for the First Time
MSC side of chassis
FT0 (fan tray)
SM0-
6 5 4 3 2 1
SM3
SM4-
11 10 9
SM7
FT1
0
8
4-3
