Cisco CRS-1 - Carrier Routing System Router Getting Started Manual page 146

Package Management Procedures
Table 6-6 Commands for Copying Package Files to the Router
Server Type
TFTP
FTP
rcp
Table 6-7
Table 6-7 Command Variables for Copying and Installing Packages from a Network Server
Variable
hostname_or_ipaddress
pie-name
username
password
directory-path
target-device
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
6-24
Command and Example
The following command syntax is used:
copy tftp://hostname_or_ipaddress/directory-path/pie-name target-device
Example:
RP/0/RP0/CPU0:router# copy tftp://10.1.1.1/images/comp-hfr-full.pie disk1:
The following command syntax is used:
copy ftp://username:password@hostname_or_ipaddress/directory-path/pie-name
target-device
Example:
RP/0/RP0/CPU0:router# copy ftp://john:secret@10.1.1.1/images/comp-hfr-full.pie
disk1:
The following command syntax is used:
copy rcp://username@hostname_or_ipaddress/directory-path/pie-name target-device
Example:
RP/0/RP0/CPU0:router# copy rcp://john@10.1.1.1/images/comp-hfr-full.pie disk1:
describes the command variables for copying and installing packages from a network server.
Description
Host name or IP address of the server that stores the source file.
Name of the PIE file (package) to install. See the
page 6-2 for descriptions of the available PIE files.
Required for FTP and rcp only and must be a valid username on the FTP or rcp server.
Required for FTP only. If a password is not provided, the networking device accepts
anonymous FTP.
The specified directory should be a directory under the home directory of the user. In the
rcp and FTP examples in this section, the file being downloaded is in a subdirectory called
"images" in the home directory of the user "john."
For FTP and rcp services, directory-path is the directory relative to the username
Note
home directory. If you want to specify an absolute path for the directory, you must
add a "/" following the server address.
disk0: PIE files are installed on the internal flash memory card disk0: with the install
•
add command. disk0: is used only for installed and active software.
disk1: PIE files can be copied to the removable flash memory card in disk1: with the
•
copy command. disk1: is used to store an archive of installation PIE files. Files can
be copied to disk1:, and then installed on disk0:.
Chapter 6 Managing Cisco IOS XR Software Packages
"Available Packages" section on
