Hardware Overview: Single-Chassis System
Figure 1-6 RP Faceplate for the Cisco CRS-1 8-Slot Line Card Chassis
RJ-45 cable
Local terminal or
terminal server for
CLI communication.
Remote terminal for
CLI communication.
Remote CLI, CWI, XML,
or SNMP communication.
Remote file storage.
Each RP contains:
•
•
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
1-8
RJ-45 cable
Ethernet cable
Network
A Management Ethernet port for 10/100/1000 Ethernet connectivity to the user network. See the
"Configuring the Management Ethernet Interface" section on page 5-2
A hard disk used for storing user files, system logs, and temporary files.
Chapter 1
Terminal connection
Console
Modem connection
AUX
ALARM
PID/VID
CRITICAL
MAJOR
MINOR
MGMT
Management Ethernet connection
ETH
for out-of-band network communication
CNTL
Optical GigE for control plane:
ETH 0
CNTL not user-configurable
ETH 1
PC
User-removable flash disk1:
CARD
stores installation PIE files.
A second internal Flash disk0:
stores installed software and
active configurations.
EXT
CLK 1
EXT
CLK 2
LED status
displays
(alphanumeric)
Primary RP (On=Primary)
Primary
Status
Card status (Green=OK)
Getting Started on the Cisco CRS-1 Router
for more information.
