Chapter 7 RP Redundancy and Hardware Administration on Cisco IOS XR Software
Figure 7-1
PL0 PL1 PL2 PL3
PL8 PL9
The nodeID components are as follows:
•
•
•
Table 7-2
Table 7-2 Location nodeID: rack/slot/module
Card Type
(the card type that you are issuing
commands to)
Route processor
Line card
Switch fabric module
Alarm cards
Fan controller cards
Displaying the nodeID for Cards in the System
Enter the show platform command to display the node IDs of installed cards. The "Node" column
identifies the node ID of the card (see
NodeID: rack/slot/module
A0 A1 A2 AM0
B0 B1 B2 AM1
PL4 PL5 PL6 PL7
PL PL PL PL PL PL
10 11 12 13 14 15
Rack=0
The rack number in a single-chassis system is always "0."
The slot is the physical slot number where the card is installed.
The module is the CPU or SP on the card that executes the commands.
summarizes the nodeID for each type of card in a single-chassis system:
Rack
(always "0" in a
single-chassis system)
0
0
0
0
0
Command Syntax for Hardware Nodes (location nodeID)
RP
Console
AUX
HDD
PC Card
(disk1:)
CNTL ETH 0
CNTL ETH 1
MGMT ETH
Primary
Status
Slot=Physical slot
of the card
Slot
(the physical slot where
the card is installed)
RP0 and RP1
0–15
SM0–SM7
AM0–AM1
FC0–FC1
Figure 7-2).
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Processors on Card
SP
CPU0
Module="CPU0" or "SP"
on the card
Module
(the entity on the card that
executes the commands)
CPU0
CPU0
SP
SP
SP
