1. Introduction

Features

This digital camera uses three 1.45 million pixel 1/2 inch IT CDD.
Newly developed 1/2 inch C mount Dichroic prism for the color separation prism.
Capable of recording semi-animation (7.5 frames per second) and still images at resolution of
1360 1024 pixels.
Image capturing capability using a capture board since video signals are processed in real-
time by the built-in DSP and outputted as RGN analog signals of 7.5 frames/sec.
Monitor output can be scan-converted to 640
@ @ @ @ @ @ 30 frame/sec. output capability to even a VGA real-time monitor (Draft mode).
Output digital still images to an MO drive or recommended printer using SCSI connection.
Export digital still images to a PC using SCSI connection.
Remotely control your PC using RS-232C connection.

Accessories and attachments

Power cable (2 m)
For connecting with AC
adapter 8-pin cable
( page 18)
Ferrite core
For power cable
( page 18)
Instruction book
Warranty card
E6
Remote plug (10-pin)
REMOTE terminal plug
( page 12)
Mini screwdriver
For replacing battery
( page 16)
Wire clamp (5 units)
For clamping rear cables, etc.
480 pixels for output to a VGA monitor.
Battery
For time and date backup
(
PC software (2 types)
• Remote control software
(For controlling the main unit
with a PC)
• SCSI import plug-in software
(For importing still images to
a PC)
For details, see the instructions
attached with the software.
(
page 16)
page 64)
