Basic system 2
This is a system to record with this camera using a flash timed by an external freeze switch.
MONITOR
SCSI
DC IN
Model name
CAUTION
Use a 1/2 inch mount microscope adapter.
To avoid damage to the unit, always use an adapter that is 4mm or less from
the lens mount side.
AA-P700
AC ADAPTER AA-P700
POWER
ON
OFF
AC adapter
REMOTE
REMOTE
Microscope
adapter
Flash
Freeze switch
AC
VGA monitor
MO disk drive
ALARM
SHEET
POWER
Printer
MITSUBISHI
CP700DSA
PAPER FEED
& CUT
COPY
ONLINE
PAPER
DATA
OPEN
4mm or less
Lens
E15
