Focus adjustment

This unit is not equipped with a back-focus feature. Adjust the back focus using the lens.
Focus ring
Shutter speed
- - - REC MENU ( QU I CK ) - - -
AE L EVE L 0
:
I R I S L EVE L : 1 2 8
SHUTERE : S TE
SPEED : 1 / 30
SENS I T I V I TY : STEP
L EVE L : I SO1 0 0
A LC MAX : I SO4 0 0
SEND PRI ORIT Y: MO
REC mode quick menu screen
The default setting of the main unit shutter speed is 1/8.
When difficult to focus, change the shutter speed to 1/30
using the procedure given below.
1.
Press the MODE button to enter the REC mode (REC
LED on). Next, lightly press the MENU button to display
the REC mode quick menu screen.
2.
Press the DOWN and SET buttons to change SHUT-
TER to STEP.
P
3.
Press the DOWN button to select SHUTTER SPEED,
then press the SET button.
1/8 will be displayed in purple, indicating that it can be
changed.
4.
Press the UP or DOWN button to change the value to
1/30, then press the SET button. When confirmed, the
set value of 1/30 will be displayed in white.
MEMO
At this time, pressing the MENU button without pressing the
SET button will not confirm the set value and the unit will re-
turn to the setting prior to the change.
5.
Press the MENU button to return to the normal screen.
Male
Female
