WHITE BALANCE screen

Menu item
COLOR TEMP
WHITE BAL
LEVEL (R)
LEVEL (B)
Function/variable range
Used to set the basic color temperature of the white bal-
ance.
3200K: for use under low color temperature such as halo-
gen lamps, etc.
5200K: for use under high color temperature such as the
sunlight, etc.
Used to set the white balance mode.
PRESET: the white balance is locked to the COLOR
TEMP setting.
(3200K:141/5200K:101)
AUTO: Used when adjusting the white balance. (
Page 30 White balance adjustment)
Fine adjustment can be made for the white
balanced using LEVEL (R) and LEVEL (B).
MANUAL: the white balance can be changed using
LEVEL (R) and LEVEL (B).
The color red of the white balance can be adjusted when
WHITE BALANCE is set to AUTO or MANUAL.
Increase the number: stronger red on the screen
Decrease the number: weaker red on the screen
[Variable range during AUTO: –32 ~ 31]
[Variable range during MANUAL: 0 ~ 255]
The color blue of the white balance can be adjusted when
WHITE BALANCE is set to AUTO or MANUAL.
Increase the number: stronger blue on the screen
Decrease the number: weaker blue on the screen
[Variable range during AUTO: –32 ~ 31]
[Variable range during MANUAL: 0 ~ 255]
Default value
3200K
AUTO
AUTO : 0
MANUAL :
128
AUTO : 0
MANUAL :
128
E51
