2. Before recording

Basic system 1

While checking the images from the camera on the monitor, output the images to an MO disk or
printer.
Connect to the
power supply
( page 18)
@ @ @ @ @ @
DC IN
For the power supply, always use the AA-P700 AC adapter.
E14
AA-P700
AC ADAPTER AA-P700
POWER
ON
OFF
AC adapter
MONITOR
SCSI
Mount the lens
( page 17)
Connect the monitor
AC
(
VIDEO IN
MO disk drive
ALARM SHEET
POWER
(recommended: Mitsubishi CP700DSA)
page 19)
VGA monitor
Connect the MO drive
unit ( page 20)
MITSUBISHI
CP700DSA
PAPER FEED & CUT COPY ONLINE
PAPER DATA
Connect the printer
OPEN ( page 21)
Printer
