LCR-II SETUP -
STEP 2: SECURITY
Press the M1 Key to access a top-level menu. Press 1 to scroll to the SECURITY menu. Press ENTER to
gain access to the secondary menu.
Security - Screen 1
USER KEY
0001
USER KEY (Password)
Use this field to enter the owner/office password. To enter a password, press ENTER to drop into
the data entry field. Enter a password using up to 10 alphanumeric characters. Press ENTER. This
password will be required in the future to unlock the system in order to gain access to secured menu
and data entry fields. This password will also be needed to change the time using the LCR-II control
buttons. If it is desired to have access to time adjustment, the USER KEY must be numeric only and
contain 5 digits.
Press 1 and the cursor will move to:
A
SECURITY
This field is used to lock the system. Press ENTER to drop to the bottom field. Use i to scroll
between LOCKED and UNLOCKED. Press ENTER to select the desired option. While the system
is LOCKED, the operator is unable to change system data other than GROSS and NET PRESETS,
PRODUCT CODE, PRODUCT NAME, and NO-FLOW TIMER.
Press M1 to return to the top-level menu. Press 1 to scroll to GENERAL SETUP.
STEP 3: GENERAL SETUP
The fields in this menu are not specific to any of the four possible product calibrations, therefore the
Selector Switch does not have to be in the CALIBRATION position to allow data entry in many of these
fields and changes can be made without breaking Weights & Measures seals.
Press ENTER and the cursor will move to:
General Setup - Screen 1
DATE FORMAT*
MM/DD/YY
A
DATE FORMAT
This field is used to determine in which format the date will be displayed and printed: month first or
day first. Press ENTER and the cursor will drop to the second line. Now you can use the arrow keys
to select the format, either month first (MM/DD/YY) or day first (DD/MM/YY). When the choice is
displayed, press ENTER and the cursor will move back to the top line.
Press 1 and the cursor will move to:
DATE MM/DD/YY (or DD/MM/YY depending on the previous field).
This field is used to set the LCR-II internal calendar. The LCR-II updates its calendar and will print the
correct date on delivery tickets. Press ENTER and the cursor will drop to the bottom line. Enter the
current date on the keypad using only numbers. Press ENTER and the cursor will move back to the
top line.
10
SECURITY & GENERAL SETUP
SECURITY*
UNLOCKED
The LCR-II is shipped LOCKED from the factory.
DATE
10/6/2002
TIME HH:MM:SS
9:05:24
