Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 13

LCR-II SETUP -
STEP 4: SYSTEM CALIBRATION
From the top-level menu, use 1 to scroll to SYSTEM CALIBRATION. Press ENTER and the cursor will move to:
System Calibration - Screen 1
| METER ID
1234567890
METER ID
This number allows you to uniquely identify an LCR-ll/Meter combination. If the LCR-II is part of a
multiple-meter system, it is important that this number be unique. It is recommended that the meter
serial number be entered here. This number will print on the calibration/diagnostic ticket. Press
ENTER and the cursor will drop tot he bottom line. Key in 1 to 10 characters. Press ENTER and the
cursor will move back to the top line.
Press 1 and the cursor will move to:
TICKET?
This field allows you to choose whether or not a ticket will be required for each delivery. Most Weights
& Measures governed truck applications will require a ticket. If YES is chosen, the LCR-II will not
allow deliveries to be made unless a ticket is in the printer, the printer is operational and the previous
delivery ticket has been printed in its entirety. Press ENTER and the cursor will drop to the bottom
line. Use 1 to scroll between the two choices, YES or NO. When the desired choice is displayed,
press ENTER. The cursor will move to the top line. When NO is selected, tickets are not mandatory
but will print if a printer is connected and available to print a ticket.
Press 1 and the cursor will move to:
A
PRINTER
This field allows you to select a printer type. The six choices are EPSON NewFontB (select for
use with EPSON 200 Roll and EPSON 220 Roll). EPSON NewFontA (select for use with EPSON
ТМ-Т88Ш), EPSON OldFontA (select for use with EPSON 290 Slip and EPSON 295 Slip), EPSON
OldFontB (select for use with EPSON 300 Roll), OKIDATA ML184T (select for use with Okidata
ML184T), BLASTER (select for use with Cognitive Solutions Thermal Printer). Press ENTER and the
cursor will drop to the bottom line. Use 4 to scroll between the choices. When the desired choice is
displayed, press ENTER and the cursor will move back to the top line.
Press 4 to move to:
System Calibration - Screen 2
| UNITSA
GALLONS
A
UNITS
This field is used to choose the units of flow measurement. The choices are GALLONS, LITRES,
CUBIC M, LBS (pounds), KGS (kilograms), BARRELS, and OTHER. Press ENTER and the cursor
will drop to the bottom line. Use the ФТ keys to scroll through the choices. When the desired choice is
displayed, press ENTER and the cursor will move to the top line.
Press 4 and the cursor will move to:
A
RATE BASE
Use this field to select the time unit for measurement on the flow rate display. The choices are rate
PER HOUR, PER MINUTE and PER SECOND. Press ENTER and the cursor will drop to the bottom
line. Use 4 to scroll between the three choices. When the desired choice is displayed, press ENTER
and the cursor will move to the top line.
Press 4 and the cursor will move to:
14
SYSTEM CALIBRATION
TICKET?
SI
RATE BASEA
PER MINUTE
PRINTER
EPSON 295 SLIP
DECIMALA RESIDUALA
TENTHS ROUND
|
|
