LCR-II Setup Overview
Make sure that the Lap Pad or other data entry device is connected to the LCR-II register as described in the LCR-II Installation
Manual.
When proving the LCR-II system, follow the pre-test and inspection procedures established by Weights & Measures authorities. The
primary indicating and recording element on a vehicle-mounted LCR-II is the 6-digit liquid crystal display.
Weights & Measures inspectors are responsible for determining if the truck metering and recording elements of the system are within
tolerance. To make this determination, the system should be tested under normal conditions.
The LCR-II is pre-programmed with common values for many of the programmable parameters. These values should be checked to
ensure that they fit the specific requirements of the given installation. Detailed instructions for checking and changing these values
follow later in this publication.
Changes cannot be made to metrologically significant data without first removing the Switchplate and its associated Weights &
Measures seal. The security level for each of the programming screens is defined in the following table:
Lap Pad Security Level Key -
OPERATOR
PASSWORD
WEIGHTS & MEASURES
FACTORY
NOT EDITABLE
This table applies to the lower line of the Lap Pad display only. The upper line cannot be edited.
LCR-II SETUP STEPS
STEP 1: REMOVE THE LCR-II
SWITCHPLATE
STEP 2: SECURITY
STEP3: GENERAL SETUP
STEP 4: SYSTEM CALIBRATION
STEP 5: PRODUCT & SHIFT INFORMATION
STEP 6: PRODUCT CALIBRATION
STEP 1: REMOVE THE LCR-II SWITCHPLATE
•
Remove the lead seal and wire assembly from the
LCR-II switchplate (if previously sealed by Weights &
Measures authorities).
•
Remove the four screws that secure the Switch Plate
over the red Selector Switch located on the front of
the LCR-II, and remove the plate.
•
Rotate the Selector Switch counter clockwise to the 6
o'clock (CALIBRATION) position to permit access to
all programming fields (except FACTORY).
for tables in this manual
Operator can change or enter data.
System must be unlocked
Switch must be in the CALIBRATION position to enter
or change data
Read Only (cannot be changed by operator)
Read Only (cannot be changed by operator)
LCR-II SETUP OVERVIEW
