Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 27

LAP PAD -
PRESET DELIVERY
PRESET DELIVERY WITH A LAP PAD (CONT'D)
PRESET
The PRESET amount can be entered here. A preset of GROSS or BOTH must have been selected in
GENERAL SETUP.
REMAINING
This field displays the number of units remaining for the current delivery. DISPLAY ONLY.
A
UNITS
This field displays delivery units selected during CALIBRATION: GALLONS, LITRES, CUBIC
METERS, LBS, KGS, BARRELS, and OTHER.
Press 1 to advance to:
Delivery & Preset - Screen 5
PRICE/UNIT
0.000
PRICE/UNIT
Enter value.
TAX/UNIT
Enter unit tax if applicable.
% TAX
Enter % Tax rate if applicable.
Press 1 to advance to:
Delivery & Preset - Screen 6
SUBTOTAL
0.000
SUBTOTAL
Price per unit times quantity. DISPLAY ONLY.
TAX
Total of all taxes for delivery. DISPLAY ONLY.
TOTAL
Sum of SUBTOTAL plus TAX. DISPLAY ONLY.
Press 1 to advance to:
Delivery & Preset - Screen 7
AUX OUT 1Л
ON DURING DELIVERY
AUX OUT1 A
This field activates optional outputs, e. g. pump control, additive injection, alarms, etc. Choices are
OFF, ON, ON DURING DELIVERY or MONITOR FLOWRATE. MONITOR FLOWRATE becomes
active at the beginning of each delivery. If the flowrate meets or exceeds 40 units/time, the output
deactivates. If the flowrate does not meet or exceed 40 units/time, the output remains active.
Л
AUX OUT 2
This field can be programmed to indicate FLOW DIRECTION or it can be programmed similar to the
AUX OUT 1
28
TAX/UNIT
0.000
TAX
0.000
AUX OUT 2Л
FLOW DIRECTION
Л
functions of OFF, ON, or ON DURING DELIVERY.
%TAX
0.000
TOTAL
0.000
