STEP 3: GENERAL SETUP (CONT'D)
Press 1 and the cursor will move to:
TIME HH:MM:SS
This field is used to set the LCR-II internal clock. The time, like the date, is updated by the LCR-II and
printed on the delivery tickets. Press ENTER and the cursor will drop to the bottom line. Enter the
current hour, minutes, and seconds. Use military time (e.g. press 13:01:15 for 1:01:15 PM).
Press 1 and the cursor will move to:
General Setup - Screen 2
|SALE#
25
SALE#
This field is used to track the number of transactions that the LCR-II processes. The LCR-II will
increment the field each time a delivery is made, wrapping around to 000000 after 999999. Press
ENTER and the cursor will drop to the bottom line. Key in the starting SALE #, up to 6 digits. Press
ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
TICKET #
This is similar to the sale number. It will increment every time that the LCR-II prints a ticket. If multiple
or duplicate tickets are used for transactions, the ticket number will be incremented more than the
sale number. NOTE: If a TICKET # of 0 is entered, the TICKET # will not print on the delivery ticket
and the TICKET # will not increment. Press ENTER and the cursor will drop to the bottom line. Key in
the starting TICKET #, up to 6 digits. Press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
UNIT ID
This is a number that can be used to identify the driver, location, or truck that the LCR-II is associated
with. Press ENTER and the cursor will drop to the bottom line. Key in your UNIT ID, up to 10
characters. Press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
NO-FLOW TIMER
The NO-FLOW TIMER is an internal timer in the LCR-II that starts running when the LCR-II senses
that there is no longer any product moving through the meter. If the timer counts up to its set point,
the LCR-II will assume that the delivery is over, and print a ticket. The timer can be set to count up
to 3600 seconds before printing the ticket. This feature can be deactivated by entering 0 seconds,
allowing multiple tanks to be filled at a location. The timer helps to ensure that deliveries are not split
between authorized and unauthorized locations. NO-FLOW TIMER is not active in prover mode. If the
value is set to 0 or any value greater than 180, "Multiple Deliveries at One Site" will be printed on the
delivery ticket.
TICKET# UNIT ID
1 123456
Internal timer is activated once the flow delivery has started and a minimum
| amount of flow (1 gallon or 5 liters) is registered and then is stopped.
GENERAL SETUP -
To synchronize the clock to the second, press ENTER
when the appropriate second is reached. Press
ENTER and the cursor will move to the top line.
NO-FLOW TIMER
180
