  • Page 1 ELECTRONIC REGISTER SETUP AND OPERATION MANUAL THE CENTER OF FUELING LOGIC...

  • Page 2: Table Of Contents

    LCR.iQ™ Setup & Operation Manual Table of Contents LCR.iQ Product Manual LCR.iQ Overview Publication Updates Safety Procedures ESD Protection Specifications Regulatory & Certifications FCC Compliance Dimensions - Panel Mount Dimensions - Meter Mount LC Offices Worldwide Setup and Operation Software License Agreement Operational Information &...
  • Page 3 Multi-point Calibration Setting the S1 Close time Setting up delivery ticket options Print the previous ticket Upgrading LCR.iQ Firmware by USB Perform a Clear All Procedure Print a transaction Setup custom profiles Print a diagnostic ticket Appendix A: K-Factor (Pulse/Unit) Chart for LCR.iQ Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual:...

  • Page 4: Lcr.iq Product Manual

    LCR.iQ - Setup and Operations Manual LCR.iQ Product Manual Congratulations on ownership of the new LCR.iQ electronic meter register and controller. This manual provides the technical details on installation, hardware, setup, operation, and regulatory information for the LCR.iQ electronic register. The LCR.iQ electronic register calculates, monitors and records volumetric data from bulk flow meters, provides fluid transfer process customization and automation, ties in critical system sensors and inputs, and bridges data communication between the operator, the equipment,...

  • Page 5: Lcr.iq Overview

    LCR.iQ Overview About the LCR.iQ The Liquid Controls LCR.iQ is a microprocessor-based electronic meter register that can be used for Weights & Measures approved custody transfer actions in mobile or fixed installations. The LCR.iQ is a self-contained unit. All operation, setup, and configuration functions can be carried out using the LCR.iQ's function keys and alphanumeric keypad.

  • Page 6: Publication Updates

    LCR.iQ - Setup and Operations Manual Publication Updates The most current versions of all Liquid Controls publications are available on our web site, www.LCmeter.com/resources/technical/manuals. If there are questions about the language or interpretation of any LC manuals, instructions, or specification sheets, please first contact your local distributor for help with your inquiry.

  • Page 7: Safety Procedures

    LCR.iQ - Setup and Operations Manual Safety Procedures BE PREPARED · Before using this product, read and understand the instructions. · All work must be performed by qualified personnel trained in the proper application, installation, and maintenance of equipment and/or systems in accordance with all applicable codes and ordinances.
  • Page 8 LCR.iQ - Setup and Operations Manual OBSERVE NATIONAL & LOCAL CODES Power, input, and output (I/O) wiring must be in accordance with the area classification for which it is used (Class I, Div 2). For North America, installations must be per the U. S. National Electrical Code, NFPA 70, or the Canadian Electrical Code in order to maintain Class I, Division 2 ratings.

  • Page 9: Esd Protection

    This electric charge can enter the LCR.iQ register from any point in the truck electrical system, including register power and printer cabling. Liquid Controls Grounding Kits All LCR.iQ truck installations must have grounded seats and printers using the following kits: ·...
  • Page 10 LCR.iQ - Setup and Operations Manual The Epson Printer Ground Wire Kit is included with each Epson printer cable kit shipment. For existing installations and previously purchased registers / printers, both ground kits are available from LC. Grounding with a Meter Mount or Remote Mount In a LCR.iQ installation where the register is mounted directly to the meter, the LCR.iQ housing is grounded through the meter.

  • Page 11: Specifications

    LCR.iQ - Setup and Operations Manual Specifications Mechanical Housing and Keypad The LCR.iQ housing and bases are aluminum die castings with chromate protective finishing and powder coated with high durability, urethane powder. The cover internal hinge design provides easy access to the internal connections and keeps all moving hinge parts out of the elements to further prevent corrosion.
  • Page 12 LCR.iQ - Setup and Operations Manual · 800 x 480 pixels (152.4 mm x 91.4 mm) · Luminance: 1500 (cd/m · Display acceptable operation or storage temperature -40 °F to 185 °F (-40 °C to 85 °C). Weight · Approximately 12 lbs (Meter Mount Version, no added accessories) ·...
  • Page 13 (meter mount option only). A pulse input can also come from an external device such as a Liquid Controls Pulse Output Device (POD) or another externally mounted pulse generator. If an external LC POD is purchased, these materials are necessary, but are not supplied with the POD: ·...
  • Page 14 LCR.iQ - Setup and Operations Manual · Current: 3 mA maximum sink current · Maximum Frequency: 10 kHz OUTPUTS The LCR.iQ is equipped with six digital outputs and four solenoid outputs. These outputs allow the LCR.iQ to communicate with meter system accessories such as solenoid- controlled valves, optical air and vapor eliminators, remote displays, printers, and third-party devices.
  • Page 15 LCR.iQ - Setup and Operations Manual Electrical Protection · 5 A fuse on power cable COMMUNICATIONS · RS-232 · RS-485 · CAN BUS – Consult the applicable Chassis Builder’s Guide, available from the truck chassis manufacturer. · Ethernet (Gigabit) · Bluetooth (wireless) ·...

  • Page 16: Regulatory & Certifications

    LCR.iQ - Setup and Operations Manual Regulatory & Certifications The equipment is Listed by UL to applicable US and Canadian standards for use in hazardous locations under Liquid Controls file E180172. Class I · Potentially Explosive Gas/Vapor Atmospheres. Division 2 and Zone II ·...
  • Page 17 LCR.iQ - Setup and Operations Manual IP66 · Ingress protection: dust tight and protected against powerful water jetting. Type 4X · The enclosure has been evaluated by UL for outdoor use to provide protection against water and dust and an increased level of protection against corrosion; and that will be undamaged by the external formation of ice.

  • Page 18: Fcc Compliance

    LCR.iQ - Setup and Operations Manual FCC Compliance Unique Identifier: LCR.iQ Responsible Party: Liquid Controls LLC 105 Albrecht Drive Lake Bluff, IL 60044 USA www.LCmeter.com FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 · Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment, not expressly approved by Liquid Controls could void the user’s authority to operate the equipment. This device complies with the ISED Canada license-exempt RSS standard(s). Operation is...
  • Page 20 LCR.iQ - Setup and Operations Manual The antenna for this equipment shall not be co-located with or operated in conjunction with any other antenna or transmitter. The antennas shall be installed and operated to maintain a separation distance of 20 cm or greater between any other radiating antenna. The FCC ID and IC can also be viewed on the LCR.iQ by pressing <Main Menu>...

  • Page 21: Dimensions - Panel Mount

    LCR.iQ - Setup and Operations Manual Dimensions - Panel Mount FRONT VIEW BACK VIEW Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 22 LCR.iQ - Setup and Operations Manual SIDE VIEW TOP VIEW Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 23: Dimensions - Meter Mount

    LCR.iQ - Setup and Operations Manual Dimensions - Meter Mount Front View Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 24 LCR.iQ - Setup and Operations Manual Side view Top View Bottom View Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 25: Lc Offices Worldwide

    IDEX Fluid and Metering Pvt. Ltd. Survey No. 256, Alindra Savli GIDC, Manjusar Dist. Vadodara 391 770 Gujarat, India +91 265 2631855 Liquid Controls Sponsler 105 Albrecht Drive Lake Bluff, IL 60044 (847) 295-1050 Toll-free: 800 458-5262 Corken 3805 Northwest 36th St.

  • Page 26: Setup And Operation

    Setup and Operation About the LCR.iQ The Liquid Controls LCR.iQ is a microprocessor-based electronic meter register that can be used for Weights & Measures approved custody transfer actions in mobile or fixed installations. The LCR.iQ is a self-contained unit. All operation, setup, and configuration functions can be carried out using the LCR.iQ function keys and alphanumeric keypad.
  • Page 27 LCR.iQ - Setup and Operations Manual OPERATOR FRIENDLY SCREENS WITH DAY / NIGHT MODES AND BRIGHTNESS CONTROL LCR.iQ screens adapt to the operator. Idle screen shows the last delivery data, changing to full screen, active fueling mode with yellow background when Start is pressed. Operators have the option to see fueling details during active fueling and can easily adjust screen brightness and toggle between day or night modes for reduced eye strain.
  • Page 28 Safety and security go hand- in-hand, and these are the number one priority at Liquid Controls. CONFIGURABLE DELIVERY SETUP Guide the operator through the fueling process of your choosing.
  • Page 29 LCR.iQ - Setup and Operations Manual CONFIGURABLE IDLE SCREEN Easily configure the idle screen fields the operator sees before, during, and after fueling. All units of measure including date and time formats are also configurable to comply with local standards. Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual:...

  • Page 30: Software License Agreement

    Agreement to any person or entity in whole or in part. 13. The waiver or failure of Liquid Controls to exercise in any respect any right provided herein shall not be deemed a waiver of any further right hereunder.

  • Page 31: Operational Information & Main Menu

    LCR.iQ - Setup and Operations Manual Operational Information & Main Menu This figure provides a visual overview of the register. In the sections below, you can find general information on the operation of the register, screen layout, types of display screens, and the keypad.

  • Page 32: Delivery Screen Layouts

    LCR.iQ - Setup and Operations Manual Delivery Screen Layouts Delivery Screens The user interacts with the register through the delivery screens. A user can view delivery details, and also enter information before, during, and after completing a transaction. There are three separate delivery screens that may appear: ·...
  • Page 33 LCR.iQ - Setup and Operations Manual Active Delivery Screen (Full Screen) The Active delivery screen appears any time the LCR.iQ is performing an active delivery. The default active delivery screen is the Full Screen mode–which displays large, bright delivery volume, along with the base regulatory details for a transaction. Active Delivery Screen - Show Details Display this screen at any time during a delivery by pressing the function key that corresponds to Show Details.
  • Page 34 LCR.iQ - Setup and Operations Manual Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 35: Display Screen Types

    LCR.iQ - Setup and Operations Manual Display Screen Types With menus, you can quickly navigate to various operational screens available within the LCR.iQ. There are two menus accessible to the user, the Main Menu and the Setup Menu. Access to the main menu is accessible from the idle delivery screens, or anytime the LCR.iQ first enters the calibration mode (in a a non-active delivery mode).
  • Page 36 LCR.iQ - Setup and Operations Manual Parameter fields display current information that has already been setup. Other general information may also be shown. There are three main types of parameter fields within an operation screen: list boxes, text fields, and read-only fields. List Box parameter fields, when selected, provide the user with a list of options that are available for that specific parameter.
  • Page 37 LCR.iQ - Setup and Operations Manual Text box: When a text box parameter field has been selected, the user can manually enter text information specific to that parameter. Text for these fields can be entered using the alphanumeric keypad. Keep in mind that a text field can either be numeric (only numbers are permitted for that parameter) or alphanumeric (either numbers or letters are are permitted for that specific parameter).
  • Page 38 LCR.iQ - Setup and Operations Manual Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 39: Keypad Interface

    LCR.iQ - Setup and Operations Manual Keypad Interface Keypad The LCR.iQ keypad serves as a tool for basic delivery functionality, data entry and screen navigation. There are three sections of the keypad, including function keys, alphanumeric keys and, navigation keys. See the detail explanations below. Function keys provide a simple way to perform specific tasks such as starting a delivery, setting a preset amount, or accessing a different menu.
  • Page 40 LCR.iQ - Setup and Operations Manual Navigation Keys give the user a simple way to move among screens, and also help in making selections. The up and down arrow keys move the selection bar up and down through screens, menus, and list boxes. The right and left arrow keys are for scrolling through setup screens, and also move a cursor left or right within a text box.
  • Page 41 LCR.iQ - Setup and Operations Manual Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 42 LCR.iQ - Setup and Operations Manual Alphanumeric Keys are primarily for data entry, such as setting a preset amount, entering a delivery prompt, or programming the register. Each alpha-numeric key has the ability to display multiple characters according to the number of times that you press a key. Press an alpha- numeric key once to display the primary key function, which is the largest character shown on each key.
  • Page 43 LCR.iQ - Setup and Operations Manual When accessing a numeric-only text box field, the alphanumeric keys will only display numbers when pressed. Pressing a key multiple times within a numeric-only field will simply display the same number (repeatedly). There is an additional alpha-numeric key that enables quick access to the most commonly used symbols on the LCR.iQ.
  • Page 44 LCR.iQ - Setup and Operations Manual NOTE: Additional symbols are available when a text box screen is displayed. A function key containing the symbols , * / = will appear. Pressing this key will display a chart of many additional available symbols.

  • Page 45: Delivery Details

    LCR.iQ - Setup and Operations Manual Delivery Details This section contains additional delivery parameters that you can configure for display on the Delivery Screens . There are three screens that contains a number of parameters each. See the explanations for each below. Delivery Details (1/3) I/O Board Name (This appears on each of the three screens)
  • Page 46 LCR.iQ - Setup and Operations Manual Product code A text field for identifying the selected product with a code. The product code will appear on most ticket formats to identify the product that was delivered. (Maximum - 5 Alphanumeric characters) Product name A text field for identifying the selected product with a specific name.
  • Page 47 LCR.iQ - Setup and Operations Manual Gross Preset A numeric text field for the gross preset value–if gross presets are accepted. (Maximum - 7 numeric characters) Multiple Deliveries? A list box in which you can specify if the Multiple Deliveries feature is to be on or off. If Multiple Deliveries is set to Yes, you can fill multiple tanks at one location without being affected by the No Flow Timer feature (see below.
  • Page 48 LCR.iQ - Setup and Operations Manual Gross Quantity A read-only numeric field that displays the current gross delivery quantity. Net Totalizer A numeric-text field that display the current accumulative net totalizer value of the selected product. This is a non-resettable totalizer. However, it is programmable in the Weight and Measures (Calibration) mode–if reprogramming is necessary.
  • Page 49 LCR.iQ - Setup and Operations Manual Auxiliary 1 Output A list box that determines how any digital output that is set to AUX 1 will operate on the selected product. To control external components, there are several features in the LCR.iQ that can be set to perform according to the Auxiliary 1 and Auxiliary 2 settings.
  • Page 50 LCR.iQ - Setup and Operations Manual · Calibrated Scaled Pulse Output – Any output set to AUX 1 Calibration Mode Settings will be a calibrated pulse output that scales according to the Pulse Output Frequency setting in the calibration mode. Auxiliary 1 Flow Rate Toggle A numeric-text field that can be used to program a flow rate set point when the Aux 1 is set to Toggle flow rate.
  • Page 51 LCR.iQ - Setup and Operations Manual · On - During Active Delivery – Any output set to AUX 1 Calibration Mode Settings will turn on (Sink to ground) when a delivery is started. It will turn off when the delivery is complete.
  • Page 52 LCR.iQ - Setup and Operations Manual NOTE: The unit label will vary depending on the unit of measure that has been set up in the LCR.iQ. Tax/Unit A numeric-only text field that is used to enter a per unit tax to be applied to the volume delivered.
  • Page 53 LCR.iQ - Setup and Operations Manual Shift Gross A read-only field that will display the total gross volume that was delivered during the currently active shift. This value will reset each time the Clear-Shift command is given and the shift ticket prints.
  • Page 54 LCR.iQ - Setup and Operations Manual End Shift Pressing the End Shift function key to end the shift. Respond to the prompt “Are you sure you want to end your shift?” with either the Yes or No function keys: · No - Returns the LCR.iQ back to the Delivery Details screen.

  • Page 55: Diagnostics

    LCR.iQ - Setup and Operations Manual Diagnostics Diagnostics screens give you easy access to view real-time diagnostics of the LCR.iQ. If a printer is available, the you can print a diagnostic ticket. These screens present important system information, as well as on screen visual indications for register state, inputs, outputs and board/sensor status.
  • Page 56 LCR.iQ - Setup and Operations Manual Flow Rate – A read-only field showing the current flow rate registered by LCR.iQ during a delivery. Pulser Reversals – A read-only field that accounts for any quadrature pulser faults registered by the LCR.iQ during a delivery. Calibration # –...
  • Page 57 LCR.iQ - Setup and Operations Manual Diagnostics Screens 3/6, 4/6 and 5/6 I/O Board inputs appear on screens 3/6 and 4/6, and 5/6. These provide a real-time view of the current status of LCR.iQ I/O board inputs. These are useful to see if an input currently has a status of on (Yellow), off (White), or error (Red).
  • Page 58 LCR.iQ - Setup and Operations Manual Diagnostics Screen 6/6 Message Logging is a tool within the LCR.iQ that allows a user to pull log files from the register and display, print and export log information within a given date range. Message Log Data Type A list box that can be used to select a data log that can be viewed on screen, printed.
  • Page 59 LCR.iQ - Setup and Operations Manual Once a log file type is selected, press the function key View Logs to display the logs on the screen within the given date range. Once the log is viewable on screen, you can press the function key Print to print the log (if printer is installed).

  • Page 60: Setup Menu

    LCR.iQ - Setup and Operations Manual Setup Menu The Setup Menu contains a list of menu options for configuring the LCR.iQ for operation. Typically, the setup menu options are set up when the LCR.iQ is installed or calibrated. Settings that are programmed using the setup menu options will affect how the register will display, print, report and operate.
  • Page 61 LCR.iQ - Setup and Operations Manual Register (1/3) W&M Jurisdiction – Selecting the proper local jurisdiction option will automatically adjust the available setup menu options and remove options that are not acceptable based on the selection. Options: · NTEP - National Type Evaluation Program - US W&M Unit ID –...
  • Page 62 LCR.iQ - Setup and Operations Manual · Cubic Meters · LBS (Pounds) · KGS (Kilograms) · Barrels · Other Residual Processing – A list box for selecting how the LCR.iQ will display volumes less than the least significant digit. Options: ·...
  • Page 63 LCR.iQ - Setup and Operations Manual Options: · 0 (0) - No decimal place · 1 (0.0) - One digit after the decimal place · 2 (0.00) - Two digits after the decimal place · 3 (0.000) - Three digits after the decimal place ·...
  • Page 64 LCR.iQ - Setup and Operations Manual setting. The time can be displayed on screen, printed on the ticket, and appear in each transaction record. Register (2/3) Sale Number – A numeric-only text field that will automatically increment one digit for each delivery or transaction that is started by the LCR.iQ.
  • Page 65 LCR.iQ - Setup and Operations Manual Setting this field to 0 will deactivate the No Flow Timer. Also, setting this field to a value of 0 or a value greater than 180 (up to 3600) may activate the “Print Multiple Deliveries Per Site Message”...
  • Page 66 LCR.iQ - Setup and Operations Manual · No - Weight presets are not allowed · Yes - Weight presets are allowed Preset Required – A list box that specifies a requirement for the user to enter a preset value for every transaction of the LCR.iQ. Options: ·...
  • Page 67 LCR.iQ - Setup and Operations Manual the register has delivered up to 1 gallon (4 Litres), then this key will disappear from the onscreen action options. Fully-packed hose: To comply with Weights & Measures requirements, it is necessary to start and stop each delivery with a fully packed hose.
  • Page 68 LCR.iQ - Setup and Operations Manual Printer Type – A list box for selecting type of printer connect to the LCR.iQ–if a printer is necessary. Options: · EPSON NewFontB - For use with EPSON 220 roll printers · EPSON NewFontA - For use with EPSON TM-T88iii (Wired) and EPSON TM-P80 (wireless Bluetooth) thermal printers ·...
  • Page 69 LCR.iQ - Setup and Operations Manual In the ticket options shown above, the minimum amount of information available is shown for each format type. Information such as ticket headers, pricing, and ticket number are options that will print on any of these formats–if data is entered into the appropriate fields. Also, there are additional fields listed in the options below that can print on all of the above tickets (when enabled).
  • Page 70 LCR.iQ - Setup and Operations Manual when temperature compensation is active. If temperature compensation is not active, all delivery amounts will automatically be Gross Delivery amounts. If using the ticket format Detailed with Totalizers, the Gross Totalizers will also be printed with the Net Totalizers when active.
  • Page 71 LCR.iQ - Setup and Operations Manual Print Volume Corrected to Message? – A list box for adding a printed line to the delivery ticket that shows the product selected is volume-corrected to the selected base temperature of the compensation table. Typical settings for base temperature at 60 °F / 15 °C–depending on the selected compensation table.
  • Page 72 LCR.iQ - Setup and Operations Manual Option: · Yes - Prints line on ticket: MULTIPLE DELIVERIES AT ONE SITE · No - No additional line is printed Print Average Flow Rate? – A list box for adding a printed line to the delivery ticket showing the average flow rate throughout the duration of a delivery transaction.
  • Page 73 LCR.iQ - Setup and Operations Manual Print Average Temperature? – A list box for adding a printed line to the delivery ticket showing the average temperature throughout the duration of a delivery transaction. Options: · Yes - Prints line on the ticket showing the AVERAGE TEMPERATURE ·...
  • Page 74 LCR.iQ - Setup and Operations Manual Print Average Density? – A list box for adding a printed line to the delivery ticket showing the average density throughout the duration of a delivery transaction. Options: · Yes - Prints line on the ticket showing the AVERAGE DENSITY ·...
  • Page 75 LCR.iQ - Setup and Operations Manual Print Weight? – A list box for adding a printed line to the delivery ticket showing the weight (reference) of a delivery transaction. Options: · Yes - Prints line on the ticket showing the WEIGHT (REFERENCE) ·...
  • Page 76 LCR.iQ - Setup and Operations Manual Number of Blank Lines Before Ticket – A numeric-only text field that will print (feed) blank lines on all tickets prior to printing any of the LCR.iQ printer text. Typically, this helps to align a ticket when using a slip printer.

  • Page 77: Meter Settings

    LCR.iQ - Setup and Operations Manual Meter Settings Meter menu options allow the user to set up information specific to the meter that is connected to the LCR.iQ. If more than one meter is to be connected to the LCR.iQ, you can set up separate Meter screens for each meter and identify each one by the I/O board # and Name fields.
  • Page 78 LCR.iQ - Setup and Operations Manual Meter ID – A text field for identifying a meter that is connected to the LCR.iQ, Typically, the serial number of the meter is entered here. The value of this field is also printed on the LCR.iQ calibration ticket.
  • Page 79 LCR.iQ - Setup and Operations Manual · Forward Count Only - A registered pulse signal, in the forward direction only, will directly affect the accumulative totalizer readings. It will also display the volume on the idle delivery screen. · Ignore - Any pulse signal that is detected when a delivery is not active will be ignored by the LCR.iQ.
  • Page 80 LCR.iQ - Setup and Operations Manual Meter (2/3) Valve Logic Type – A list box field that is used to select the logic to be used when connecting a solenoid valve to the LCR.iQ. Options: · Two-Stage Preset Valve - This logic is to be used with standard 2 stage preset valves. With this logic, only S1 will open for full flow when a delivery starts.
  • Page 81 LCR.iQ - Setup and Operations Manual Minimum Meter Flow Rate – A numeric text field that can be used to set a minimum flow rate value for the LCR.iQ. If the delivery flow rate drops below this value for a duration greater than the Minimum Flow Rate Timeout value, the delivery will be paused by the register and an error message generated to inform the user that the Minimum Flow Rate was detected.
  • Page 82 (Maximum setting - 15 sec) Meter (3/3) Maximum Filter Flow Rate – A numeric only text field that is used along with a Liquid Controls Differential Pressure Transducer (dP) to calculate corrected differential pressure based on the maximum rated flow rate of the filter vessel. This field should be set to the maximum flow rate rated on the filter housing.
  • Page 83 LCR.iQ - Setup and Operations Manual Weight – A read only field that displays a weight value when using Liquid Controls Automatic Density Sensor or entering a manual density value into the LCR.iQ. Weight Unit of Measure – A list box field that is used to select the unit of measure for weight when using this feature.

  • Page 84: Calibration Settings

    LCR.iQ - Setup and Operations Manual Minimum Flow Rate Density – A numeric text box that can be used to set a minimum acceptable flow rate value when calculating density. This value should vary based on the acceptable minimum flow rate of the meter and should never be set below the minimum rated volumetric flow rated on the meter.
  • Page 85 LCR.iQ - Setup and Operations Manual · Products 1-16 are available for setup. Only setup and calibrate products that are to be used by the LCR.IQ. Product Type – A list box for selecting the product (classification) type. The product type will print on all calibration and diagnostic ticket,s and it will designate the Product Type for each Product Number.
  • Page 86 LCR.iQ - Setup and Operations Manual adjust the Pulse/Unit field by the percent error that is calculated. Learn more in Single-point Calibration Linearization Mode – A list box for applying multi-point calibration, when such calibration is in use. Setting this field to Applied will activate multi-point calibration, if all parameters have been met for using multi-point calibration.
  • Page 87 LCR.iQ - Setup and Operations Manual Compensation Parameter – A numeric-only field whose parameter is dependent on the LCR.iQ Parameter Range listed in the compensation table that was chosen in the list box. Base Temperature – A numeric-only field that sets the base temperature according to the LCR.iQ compensation table that was chosen in the list box.
  • Page 88 LCR.iQ - Setup and Operations Manual Options: · Products 1-16 are available for setup. Only setup and calibrate products that are to be used by the LCR.iQ. Product code – A text field for identifying the selected product with a code.The product code will appear on all ticket formats to identify the product that was delivered, as shown above.
  • Page 89 LCR.iQ - Setup and Operations Manual · Whole - Max 50% of the K-Factor Pulse Output Edge – A list box that determines the signal direction of the calibrated pulse output. Toggling this setting can help align the pulse output of the LCR.iQ with a remote counter or injection system by inverting the output square wave resulting in an opposite adjustment in the signal.
  • Page 90 LCR.iQ - Setup and Operations Manual · On - Reverse Flow - Any output set to AUX 1 Calibration Mode Settings will be off when a delivery starts, and will only turn on when the register detect flow in the negative or reverse direction.
  • Page 91 LCR.iQ - Setup and Operations Manual · On - Any output set to AUX 2 Calibration Mode Settings will always be on (Active and Sinking to ground) · On - During Active Delivery - Any output set to AUX 2 Calibration Mode Settings will be on (Active and Sinking to ground) when a delivery is active on the LCR.iQ.
  • Page 92 LCR.iQ - Setup and Operations Manual However, it can be programmed as necessary in the Weight and Measures (Calibration) mode if reprogramming is required. (Maximum setting - 999999999 units) Gross Totalizer – A numeric text field that shows the current accumulative gross totalizer value of the current selected product on the LCR.iQ.
  • Page 93 LCR.iQ - Setup and Operations Manual Options: · Gallons · Litres · Cubic Meters · LBS (Pounds) · KGS (Kilograms) · Barrels · Other Secondary Unit Multiplier – A numeric text field for applying a multiplying factor to the primary unit of measure in order to obtain a secondary unit of measure. An example of this would be a primary unit of measure in Gallons together with a multiplier of 3.78 that is entered to create a secondary unit of measure in Litres.
  • Page 94 LCR.iQ - Setup and Operations Manual Product # – A list box containing the 16 products that are available for setting up and calibrating the LCR.iQ. NOTE: · Products 1-16 are available for setup. Only setup and calibrate products that are to be used by the LCR.IQ.

  • Page 95: Security

    LCR.iQ - Setup and Operations Manual during the multi-point calibration run. This action will store the point and flow rate, then calculate the percent error to be applied to the selected point. Point – A list box for selecting the calibration point for the multi-point calibration. The LCR.iQ is able to perform a multi-point calibration on as many as 16 separate points.
  • Page 96 LCR.iQ. This user defined key should be set and saved by an owner or maintenance manager for secure access to these menus and features. Contact Liquid Controls customer support if you misplace or forget your user key. The user key is retrievable through the factory-calibration mode only.

  • Page 97: I/O Setup

    · No - Make no selection and return to Security Mode (or press Cancel) Factory Key – Consult Liquid Controls for factory Key information and access. I/O Setup I/O setup screen are used to setup and configure the various available inputs and outputs of the LCR.iQ, and also activate and deactivate services such as printing, LCP communication,...
  • Page 98 LCR.iQ - Setup and Operations Manual I/O Setup (1/3) · COM0 - COM4 · Number of I/O Boards · LCP Node Address Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 99 LCR.iQ - Setup and Operations Manual I/O Setup (2/3) · Digital Inputs 1-7 I/O Setup (3/3) · Digital Outputs 1-6 and Solenoid Outputs S1-S4 Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 100: Customize Home Screen

    LCR.iQ - Setup and Operations Manual Customize Home Screen The Custom Home Screen menu permits the user to setup and configure various parameters that appear on the home screen. In these screens, the user can select from a series of default profiles that are common to an industry, or create a custom arrangement from the available drop-down selection options for each line.
  • Page 101 LCR.iQ - Setup and Operations Manual Preconfigured Refined Profiles are basic screen profiles that are tailored to aviation refined fuel industry standards and available options. Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 102 LCR.iQ - Setup and Operations Manual Preconfigured Aviation Profiles are basic screen profiles that are tailored to aviation industry standards and available options. Custom Home Screen design can be done by selecting the Custom profile options. Use the navigation keys to scroll the cursor to the column (Left or Right) and field (1-6) then press OK to view the available list of fields that can be displayed.

  • Page 103: Configure Delivery Setup

    LCR.iQ - Setup and Operations Manual Configure Delivery Setup This setup configures the delivery options available when the setup delivery function key is displayed. The LCR.iQ has several preconfigured delivery setup options that correspond to the specific industries. Or, a custom configuration can be setup using the custom option. There are two basic LCR.iQ screens as well as pre-configured screens for common markets such as LPG, Refined Fuel and Aviation.
  • Page 104 LCR.iQ - Setup and Operations Manual Preconfigured LPG Profiles are basic screen profiles that are tailored to propane industry standards and available options. Preconfigured Refined Profiles are basic screen profiles that are tailored to refined fuel industry standards and available options. Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual:...
  • Page 105 LCR.iQ - Setup and Operations Manual Preconfigured Aviation Profiles are basic screen profiles that are tailored to aviation industry standards and available options. Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 106 LCR.iQ - Setup and Operations Manual Customizing the Home Screen can be done by selecting Custom profile options: Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...

  • Page 107: Operating The Lcr.iq

    LCR.iQ - Setup and Operations Manual Operating the LCR.iQ This chapter covers all of the operations that you can perform with the LCR.iQ: · Performing a basic delivery with the LCR.iQ · Performing a preset delivery - Preset Key · Using the Info button ·...

  • Page 108: Performing A Preset Delivery - Preset Key

    LCR.iQ - Setup and Operations Manual While a delivery is active, it is possible to view detailed delivery information by pressing the Show Details button. The detailed information displayed is configurable depending on the profile which can be configured on any register. A separate how to instruction on setting up a profile is available.

  • Page 109: Performing A Preset Delivery - Delivery Setup

    LCR.iQ - Setup and Operations Manual Follow these steps: 1. To access information using the Info button, navigate to any available field and press OK to access the field data. 2. Once in the field data, the screen will display a function key labeled Info. 3.
  • Page 110 LCR.iQ - Setup and Operations Manual Add to a Preset If you have started a preset delivery and you need to add to the amount, or if you are using the multiple preset type option, it is possible to add to or append the preset amount. Simply press the Stop key, then press the Preset key and a prompt will be shown on the screen to enter a new preset volume.

  • Page 111: Using The Hose Reset Feature

    LCR.iQ - Setup and Operations Manual Multiple Presets For applications in which you have an initial preset volume, but the final preset volume has not been determined, it is best to use the multiple preset option. Multiple preset allows the user to set a preset amount.
  • Page 112 LCR.iQ - Setup and Operations Manual To begin the calibration process, you must first put the LCR.iQ into the calibration mode by removing any existing seal wire and loosening the calibration bolt on the side of the register housing approximately 5-6 turns. If a ticket printer is connected to the LCR.iQ, make sure a ticket is in place and the printer is ready.

  • Page 113: Multi-Point Calibration

    Multi-point calibration takes advantage of the steadfast repeatability of a Liquid Controls meter by identifying the amount of inaccuracy and correcting it with a linearizing algorithm during deliveries.
  • Page 114 LCR.iQ - Setup and Operations Manual In the Calibration screen 4/4 you will notice that there is a yellow key labeled Run Calibration. Pressing this key will begin the actual calibration process by performing the meter screen test and resetting the delivery volume to 000.000. At the same time, the LCR.iQ will provide the permissive signal to the valve output to allow flow through the meter.

  • Page 115: Setting The S1 Close Time

    S1 closure. If you see that the unit is not presetting accurately, or it is over or under-shooting, then increase the S1 closure until the issue is resolved or consult with a Liquid Controls factory trained technician.

  • Page 116: Setting Up Delivery Ticket Options

    LCR.iQ - Setup and Operations Manual Setting up delivery ticket options Setup of a delivery ticket on the LCR.iQ can primarily be completed in the Register screen 3/3. In this screen, the base ticket format can be selected as well as additional printed lines that are available.

  • Page 117: Upgrading Lcr.iq Firmware By Usb

    Upgrading the LCR.iQ firmware is straightforward. This guide explains how to upgrade the firmware with a USB drive. Follow these steps: Obtain the firmware upgrade from the Liquid Controls website (if available) or a factory representative. The firmware will be named SR1000_Vx.xx.xx.deb (x.xx.xx represents the current firmware version number).
  • Page 118 LCR.iQ - Setup and Operations Manual Navigate to the Setup Menu option and press OK. Navigate to the Security option and press OK. Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 119 LCR.iQ - Setup and Operations Manual 10. Press the function key labeled Firmware Upgrade. 11. Select Copy Files from USB option and press OK. This will copy the firmware from the USB drive to the drive of the LCR.iQ. However, you must continue to complete the load process.

  • Page 120: Perform A Clear All Procedure

    LCR.iQ - Setup and Operations Manual Perform a Clear All Procedure In some cases it may be necessary to perform a Clear All procedure and reset all of the program settings back to the factory default. This is usually done by a factory trained technician that is upgrading software, transferring a board from unit to unit, or if a memory clear is needed.

  • Page 121: Print A Transaction

    LCR.iQ - Setup and Operations Manual Print a transaction The LCR.iQ is capable of reprinting transaction using the transactions data log screens. The register is able to store a number of transactions in its memory, corresponding with the number of days retained (which is set in the Logging setup). The default setting is to retain transaction logs for 365 days before deleting them from memory.

  • Page 122: Setup Custom Profiles

    The profile field setting will determine the information that is to be displayed on the delivery screen and in the Delivery setup options. Liquid Controls has included several pre- configured profiles in the LCR.iQ to help simplify the setup process. Optionally, you can create a custom profile.

  • Page 123: Print A Diagnostic Ticket

    LCR.iQ - Setup and Operations Manual Follow these steps to set up a custom profile (Configure Delivery Setup): 1. Navigate to the Configure Delivery Setup screen by pressing the left or right navigation keys. 2. Select the Custom profile from the Profile list box and press OK. 3.

  • Page 124: Appendix A: K-Factor (Pulse/Unit) Chart For Lcr.iq

    LCR.iQ - Setup and Operations Manual Appendix A: K-Factor (Pulse/Unit) Chart for LCR.iQ Get the latest PDF manual: https://www.lcmeter.com/resources/technical/manuals Mobile/online version of this manual: https://www.lcmeter.com/manuals...
  • Page 125 L I Q U I D C O N T R O L S An IDEX Energy & Fuels Business 105 Albrecht Drive Lake Bluff, IL 60044-2242 1.800.458.5262 1.847.295.1050 Fax: 1.847.295.1057 © 2019 Liquid Controls www.LCmeter.com LCR.iQ_Operations Manual_V1: 0119 PN#: 500432...
