STEP 6: PRODUCT CALIBRATION - SINGLE POINT
Press M1 to return to the top-level menu. Press i to scroll to PRODUCT CALIBRATION.
There are four product calibrations that can be set up in the LCR-II. The products are calibrated one at a time. Press
ENTER and the cursor will move to:
Product Calibration - Screen 1
#A
1
A
# (Product Number)
This number will correspond to one of the four product types/calibrations that can be set up in the
LCR-II. At least one calibration must be set up to allow deliveries. Press ENTER and the cursor will
drop to the bottom line. Use i to scroll between the four choices, 1 to 4. Press the ENTER key when
the desired choice is displayed.
Press 4 and the cursor will move to:
CODE
A five character alphanumeric code can be entered here. The code will correspond to one of the
products within this product type. This code can also be entered in the DELIVERY & PRESET menu.
Press ENTER and the cursor will drop to the bottom line. Enter a code that will aid the operator in
identifying the product or one that has been specified for use by a host computer system. Press
ENTER and the cursor will move to the top line.
Press 4 and the cursor will move to:
PRODUCT NAME
The PRODUCT NAME contains a product description (up to 18 alphanumeric characters) that will
print on the delivery ticket. NOTE: Make sure that the PRODUCT NAME matches up with the PROD
A A
TYPE , # , and CODE that are also entered on this screen. This name can also be entered in the
DELIVERY & PRESET menu. Press ENTER and the cursor will drop to the bottom line. Enter the
appropriate PRODUCT NAME. Press ENTER and the cursor will move to the top line.
Press 4 and the cursor will move to:
A
PROD TYPE
This field will scroll along with the #
type AMMONIA, AVIATION, DISTILLATE, GASOLINE, METHANOL, LPG, LUBE OIL and "blank"
can also be set up in the PRODUCT & SHIFT INFORMATION menu.
Press 4 and the cursor will move to:
Product Calibration - Screen 2
| COMPENSATION TYPE
TABLE 54B
COMPENSATION TYPE
Select the type of Temperature Volume Compensation to be used for this specific product number. No
deliveries are permitted if the LCR-II is configured for temperature compensation and the temperature
circuit has failed or the measured temperature is out of the specified range (see Table in Appendix A).
SINGLE POINT CALIBRATION -
CODE PRODUCT NAME
12345 Product Name
A
(Product Number) that is shown in the first field. The product
COMP PARAM
653
A
I
PRODUCT TYPE
DISTILLATE
BASE TEMP
15.0
