Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 28

Diagnostics
Most of the DIAGNOSTICS fields are for DISPLAY ONLY. They contain information that can be useful in
troubleshooting.
Diagnostics - Screen 1
DIAGNOSTIC MESSAGES*
TVC ACTIVE
DIAGNOSTIC MESSAGES'
This field allows an operator to check pending diagnostic messages. Press ENTER and the cursor
will drop to the second line of the screen. Press 1 to scroll through the list of messages. The last
message is "END OF LIST".
SUPPLY VOLTAGE
The field shows the current supply voltage. The correct operating voltage is +9 to +28 VDC. DISPLAY
ONLY. NOTE: Voltage above +17 VDC will not indicate correctly.
Press 1 to advance to:
Diagnostics - Screen 2
SOFTWARE
SR260vl.xx
SOFTWARE
The software number is shown here. This number is critical for any troubleshooting discussions with
the Liquid Controls factory service personnel. DISPLAY ONLY.
LANGUAGE
The software number designating language selection (English, Spanish, etc.) is displayed here.
DISPLAY ONLY.
TICKET
The software number designating the ticket format is displayed here. DISPLAY ONLY.
Press 1 to advance to:
Diagnostics - Screen 3
GROSS COUNT
0
GROSS COUNT
This field displays a running total of the gross number of units for the current delivery. DISPLAY
ONLY.
RATE
This field displays the actual flow rate. DISPLAY ONLY.
UNITS
This field displays the units of measure for flow total.
RATE BASE
This field displays the time base for flow rate.
Press 1 to advance to:
Diagnostics - Screen 4_____________________________________________
PULSR FAULTS
_
PULSER FAULTS
This field displays the number of quadrature pulser faults detected during the last delivery. DISPLAY
ONLY.
SUPPLY VOLTAGE
13.5
4
LANGUAGE
SL200vl.xx
RATE UNITS*
0.0 GALLONS
DIAGNOSTICS -
TICKET
ST200vl.xx
| RATE BASE* |
PER MINUTE
