Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 16

STEP 5: PRODUCT & SHIFT INFORMATION
Press ENTER and the cursor will move to:
Product & Shift - Screen 1
#A
1
A
# (Product Number)
This field is used to select one of four possible product types/calibrations. Press ENTER and the
cursor will drop to the bottom line. Use 1 to scroll through the numbers 1-4. When the product number
is selected for which corresponding PROD TYPE
cursor will move to the top line.
Press 4 and the cursor will move to:
A
PROD TYPE
This field will scroll along with the #
type AMMONIA, AVIATION, DISTILLATE, GASOLINE, METHANOL, LPG, LUBE OIL or "blank" can
be selected. Press ENTER and the cursor will drop to the bottom line. Press 4 to scroll through the
available options. When the desired choice is displayed, press ENTER and the cursor will move to
the top line.
Press 4 and the cursor will move to:
SHIFT START
The starting time and date for the current shift are shown here. DISPLAY ONLY.
DLVRY
This field shows the number of deliveries that have been made since the last time CLR SHIFT was
set to YES or a shift ticket was printed. DISPLAY ONLY.
Press 4 and the cursor will move to:
Product & Shift - Screen 2
#A
1
A
# (Product Number)
This field is used to select one of four possible product types/calibrations that can be set up in the
LCR-II. At least one calibration must be set up to allow deliveries.
SHIFT GROSS
This field displays the gross number of units that have been delivered through the meter since the last
time the CLR SHIFT field was set to YES or a shift ticket was printed. SHIFT GROSS is the sum total
of the delivery ticket gross quantities during the current shift. DISPLAY ONLY.
Press 4 and the cursor will move to:
SHIFT NET
This field displays the net (temperature compensated) number of units that have been delivered
through the meter since the last time CLR SHIFT field was set to YES or a shift ticket was printed.
SHIFT NET is the sum total of the delivery ticket net quantities during the current shift. DISPLAY
ONLY.
PRODUCT & SHIFT INFORMATION -
PROD TYPE
DISTILLATE
A
(Product Number) that is shown in the first field. The product
SHIFT GROSS SHIFT NET
1647.6 0.0
SHIFT START
7/01/2002 1:44:00
A
information will be entered, press ENTER and the
UNITS
GALLONS
LCR-II SETUP
DLVRY
22
|
17
