LCR-II SETUP -
STEP 6: PRODUCT CALIBRATION - SINGLE POINT (CONT'D)
AUX MULT
This field is used to convert the quantity delivered, (e.g. GALLONS, LITRES) to an alternate volume
or mass unit such as CUBIC METERS, LBS, etc. The user must furnish an applicable conversion
factor. If AUX MULT is set to 0, it will not print on the delivery ticket. Example: To convert GALLONS
to LBS, AUX MULT is calculated as follows:
AUX QTY
This field is used to display the volume delivered in terms of the alternate volume or mass unit.
A
AUX UNIT
This field is used to define the auxiliary unit of measure that will be printed on the delivery ticket, i.e.,
GALLONS, LITRES, CUBIC M, LBS, KGS, BARRELS, or OTHER.
Press 4 and the cursor will move to:
Product Calibration - Screen 7
PT л
RATE
1 0.00
A
PT
This field is used to calibrate the meter/register at up to 10 different flow rates for each product type/
calibration.
RATE
This field displays actual flow rate during delivery. Enter the actual flow rate for multi-point calibration.
A
UNITS
Choose the units of measure to be displayed. The choices are GALLONS, LITRES, CUBIC M, LBS
(pounds), KGS (kilograms), BARRELS, or OTHER. Use the hi keys to scroll through the choices.
Press ENTER to make a selection.
A
RATE BASE
Choose the time unit for measurement on the flow rate display. The choices are units PER HOUR,
PER MINUTE and PER SECOND. Use the 14 keys to scroll through the choices. Press ENTER to
make a selection.
%ERROR
This field contains the %ERROR difference against the base number.
% Error = --------------------------------
Press 4 and the cursor will move to:
22
SINGLE POINT CALIBRATION
AUX MULT= (SpGr) x (8.345 Ibs/gal)
(Where SpGr is the specific gravity.)
UNITSA
GALLONS
(Prover Quantity - Meter Quantity)
Prover Quantity
RATE BASE*
PER MINUTE
x luu
%ERR0R |
0.000
