LCR-II SETUP -
STEP 3: GENERAL SETUP (CONT'D)
NO-FLOW TIMER CONTINUED
Press ENTER and the cursor will drop to the bottom line. Enter the desired NO-FLOW TIMER value
inseconds. Press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
General Setup - Screen 3
PRESETA
GROSS
A
PRESET
Available preset options include NET, BOTH, GROSS, and NONE. Selecting NONE will disable
presetting. Presetting NET, GROSS, or BOTH is allowed. Press ENTER and the cursor will drop
to the bottom line. Use 1 to scroll through the available preset options. When the desired option is
displayed, press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
A
PRESET TYPE
There are four preset types:
CLEAR
RETAIN
MULTIPLE
INVENTORY
Press ENTER and the cursor will drop to the bottom line. Use 1 to scroll through the four options.
When the desired choice is displayed, press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
PULSE OUTPUT EDGE
This feature allows you to synchronize the calibrated pulse output waveform with the requirements of
an external system that uses that LCR-II signal. There are two choices: RISING or FALLING. (Some
counters increment on rising, others on falling pulse edges. Refer to equipment technical manual to
determine the specific requirements of your connected equipment). Press ENTER and the cursor
will drop to the bottom line. Use 1 to scroll between the two choices. When the desired choice is
displayed, press ENTER and the cursor will move to the top line.
Press 1 and the cursor will move to:
12
GENERAL SETUP
PRESET TYPEA
CLEAR
Resets the preset values to 0 after the current delivery is ended.
Maintains the preset values to be used again on the next delivery.
Allows more than one preset to be run before a delivery ticket is printed. Printing must be
initiated by a PRINT command.
Maintains the remaining preset amount between deliveries (i. e. indicates the remaining
volume in the vehicle tank).
A
PULSE OUTPUT EDGEA
RISING
