SINGLE POINT RECALIBRATION/PROVING (CONT'D)
Repeat the process above for each digit position until the value for each has been selected. When the least significant
digit is entered, the k-Factor is recalculated and the display returns to Calibration - Screen 1.
101.663
When this process is complete, turn the Selector Switch clockwise
out of the Calibration Position and replace the Switch plate.
CALIBRATION MENU
PROVING WITHOUT A LAP PAD -
If the new value entered is out of range for the LCR-II,
"Error" will appear in the display. If this occurs, press
SELECT to return to the Prover Quantity display.
Repeat the process by beginning a new prover run.
CALIBRATION - SCREEN 1
SELECT
CALIBRATION - SCREEN 2
Prod 1
SELECT
CALIBRATION - SCREEN 3
F 70.0
SELECT
CALIBRATION - SCREEN 4
SELECT
CALIBRATION - SCREEN 5
101.663
SELECT
If an unacceptable
value is entered.
ERROR SCREEN
SELECT
Error
LCR-II OPERATION
Step-by-step instructions on conducting a
recalibration/proving run appear in Appendix E.
INCREASE
"Current Deliv¬
ery Active"
