Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 29

LAP PAD -
FACTORY CALIBRATION
Factory Calibration -
Factory Calibration - Screen 1
R100.0
-105.2
R100.0
Used by qualified personnel to calibrate the temperature probe.
R128.6
Used by qualified personnel to calibrate the temperature probe.
RAW ADC
This is the raw value being returned by the A to D converter used by the temperature probe and can
be used to assist qualified personnel in troubleshooting.
RTD SLP
The RTD Slope is displayed here. This value can assist qualified personnel in troubleshooting.
RTD OFS
The RTD Offset is displayed here. This value can assist qualified personnel in troubleshooting.
Press 1 to advance to:
Factory Calibration - Screen 2
SERIAL ID
7200015
SERIAL ID
The LCR-II printed circuit board serial number is shown here.
USER KEY
This is where the owner/office password is entered or viewed. When the system is locked, the
operator will be prevented from changing field entries with the exception of GROSS and NET
PRESET, PRODUCT CODE, PRODUCT DESCRIPTION and NO-FLOW TIMER. If the password is
lost or forgotten, it can be recovered by the factory in this screen.
LCR RESET
This is a factory-entered value that will assist qualified personnel in clearing out memory problems,
should they arise.
30
only accessible by LC factory personnel
R128.6 RAW ADC
2884.7 796
USER KEY
A complete flow chart of the Lap Pad Menu structure appears in Appendix D.
RTD SLP RTD OFS
0.02475 2.605
LCR RESET*
NO
