STEP 6: PRODUCT CALIBRATION - SINGLE POINT (CONT'D)
Product Calibration - Screen 8
PT
PROVER QTY
A
1 0.000
A
PT
This field is used to calibrate the meter/register at up to 10 different flow rates for each product type/
calibration.
PROVER QTY
This field needs to contain the exact volume in the prover tank tested at actual flow rate. When
an entry is made, the actual %ERROR (delivery) against the base number will be recalculated
automatically.
A
UNITS
Choose the units of measure to be displayed. The choices are GALLONS, LITRES, CUBIC M, LBS
(pounds), KGS (kilograms), BARRELS, or OTHER. Use the ТФ keys to scroll through the choices.
Press ENTER to make a selection.
%ERROR
This field contains the %ERROR difference against the base number.
% Error = --------------------------------
A
LINEAR
Select SETUP for single-point calibration or when setting up multi-point calibration. Select APPLIED
to activate multi-point calibration.
See pages 23-24 for optional multi-point calibration instructions. If your LCR-II is set up
for single-point calibration, this concludes the Initial Calibration and Set-up procedures.
SINGLE POINT CALIBRATION -
| UNITSA
GALLONS
(Prover Quantity - Meter Quantity)
Prover Quantity
Proceed to Page 25 for BASIC OPERATION instructions.
| %ERR0R |LINEARA
0.000 SETUP
x luu
