APPENDIX В -
OPERATION USING VT 100 COMPATIBLE TERMINAL
If the LCR-II is operated using a VT 100 compatible terminal (instead of the LC Lap Pad), refer to the following chart
for the terminal keystrokes that correspond to the Lap Pad keystrokes. VT 100 communication parameters that must
be observed include:
•
Baud Rate (9600)
•
Data Bits (8)
•
Parity (None)
•
Stop Bits (1)
•
Flow Control(None).
Operation
Return to Top Level Menu
Move to Next Menu Item
Move to Previous Menu Item
Select Item
Submit Data and Return
Move to Next Field
Move to Previous Field
Clear Field/Start Data Entry
Start
Stop
Print
Move to Next Screen
46
Lap Pad Keystroke
M1
i
h
ENTER
ENTER (after data entry)
i
h
Clear
Start
Stop
Print
M#
PC Terminal Emulation
<control L>
<control D>
<control U>
ENTER
ENTER (after data entry)
<control D>
<control U>
Backspace
<control B>
<control S>
<control P>
<control N>
