Liquid Controls LectroCount LCR-II E36 Series Setup & Operation page 15

LCR-II SETUP -
STEP 4: SYSTEM CALIBRATION (CONT'D)
A
T UNIT
This field allows you to choose the temperature units - Degrees Fahrenheit or Degrees Celsius. Press
ENTER and the cursor will drop to the bottom line. Use 1 to scroll between the two choices, DEG. F
and DEG. C. When the desired choice is displayed, press ENTER and the cursor will move to the top
line.
Press 1 and the cursor will move to:
RTD SLP
Factory calibration setting only. Press 1 and the cursor will move to:
RTD OFS
Factory calibration setting only. Press 1 and the cursor will move to:
System Calibration - Screen 4
| FLOW DIRA
-->
A
FLOW DIR
This field allows you to match the LCR-II flow direction to the meter's pulse output. If the counter runs
backwards, this arrow should be changed. The choices are <- or Press ENTER and the cursor
will drop to the bottom line. Use 1 to scroll between the two choices. When the desired choice is
displayed, press ENTER.
Press 1 and the cursor will move to:
LAST CALIBRATED
This field contains the date and time of the last calibration. It cannot be edited.
Press 1 and the cursor will move to:
LCR#
This field contains the node address for RS485 communication. Enter a number between 1 and 250.
The default value is 250.
Press 1 and the cursor will move to:
System Calibration - Screen 5
CALIB#
34
CALIB #
For metrology use only. This is the number of times the calibration switch position has been entered.
DISPLAY ONLY.
CALIB EVENT
For metrology use only. This is the number of times the calibration has been changed. DISPLAY
ONLY.
CONFIG EVENT
For metrology use only. This is the number of times the configuration has been changed. DISPLAY
ONLY.
Press the M1 key to return to the top of the SYSTEM CALIBRATION menu. Then press 1 to scroll to PRODUCT &
SHIFT INFORMATION.
