The mechanical parts can be readily cleaned with a damp cloth and a neutral detergent. The drive motor is
in a waterproof capsule so this can be treated in a similar way without damage. After cleaning, all parts
should be dried off thoroughly.
Mounting the spillage tray:
- Replacing the spillage tray is the reverse of the instructions above.
- Replace the table and drip tray, then insert and tighten the retaining screws*.
IMPORTANT: Tighten the screws * alternating crosswise (as for the wheels of a car). One-
sided tightening of the screws may cause poor fixing of the table and thus considerable
damage to the equipment.
11.

Spare Parts

Should your shaker suddenly show defects please contact your dealer or the nearest INFORS
representative. The exchange of the usual spare parts is so easy that it can be done by the
customer himself.
In case you will ask one of our INFORS representatives for advice please give type and serial
number of the shaker. Both are written on the identification plate (see point 15.1).
11.1

Exchange of the electronics-box

In the case of a defect with the electronics (control of the shaker drive or temperature) as well as
any problem with the display, power supply or fans, a simple replacement of the electronic box as a
single component is all that is needed. This exchange can be carried out by the user themselves, if
necessary. An order can be placed for this component using our proven and cost-effective INFORS
exchange system.
Exchange of the electronics box takes place in the following way:
- Switch the equipment off at the mains and withdraw the power cable.
Open the door of the incubation chamber.
-
Remove two crosshead screws on the ceiling of the chamber, near the fan, see. Fig. 11.
-
Remove the cable from the left side of the electronics box, pressing the catch to release!
-
Push the electronic box out a little way from the back of the unit.
-
Now pull out the electronic box completely from the front of the unit.
-
(Operating-Manual_Ecotron _e) page 33 of 53
