08 May 2013
6.2.3
Operation
Switching the shaker operation ON and OFF.
With the Ecotron®, loads can be shaken from 20-450 RPM
(with optimum loading).j
Check that the main power switch in the middle oof the
operating panel is ON (see Chapter. 7.1).
The incubation chamber light is switched on for 2 minutes at
the first touch of any key.
Press the left hand ON/OFF key to turn on the shaker drive.
After pressing the key, the shaker speed display will briefly
show if this function is switched on or off.
The drive first begins to work after the incubation chamber door
has been closed.
If the door is open, the speed display will show "OPn".
While the shaker drive is switched on and operational (door
closed), the actual shaker speed is displayed. If this function is
switched off and the door is closed, then the display alternates
between OFF and the set point value.
The set point display changes after 2 seconds to either show on or off, depending on the
contoller status.
Adjusting the set point.
The incubation chamber light is switched on for 2 minutes at the first
touch of any key.
Briefly press either the +
displayed.
The set point can be increased or reduced in steps of steps of 10
rpm using repeated single presses of the + or – keys.
Hold down the left hand + key for a time and the set point will
increase continuously or hold down the left hand – key instead and
the set point decreases continuously.
(Operating-Manual_Ecotron _e)
or – key and the set point will be
page 20 of 53
O
F
F
O
F
F
O
F
F
+
O
F
F
O
F
F
-
x1
RPM
+
O
N
O
N
O
N
-
RPM
+
1
0
0
1
0
0
1
0
0
-
RPM
+
1
0
0
1
0
0
1
0
0
1
0
0
1
0
-
RPM
x1
+
9
9
9
-
RPM
hold
+
8
8
8
-
0
0
0
0
0
0
0
RPM
