Fig. 9: Mounting the outlet drain pipe.
The spill tray is NOT suitable for steam sterilization in an autoclave. In the case of heavy contamination, it's
cost effective to dispose of this component and replace it (Mounting: see Chapter 10.4).
10.4

Opening of the Shaker Table and spill tray

Switch off at the mains switch and withdraw the power cable.
-
- In the case of the optional tray with adhesive matting being fitted, remove the 4 crosshead
screws (see Chapter 7.6) to release the tray.
Remove the 4 screws (sunken head with inner hexagon M6 x 12) in the shaker table (see
-
chapter 9).
(Operating-Manual_Ecotron _e) page 31 of 53
