Infors HT ECOTRON Manual page 22

08 May 2013
Adjusting the set point
The incubation chamber light is switched on for 2 minutes at the
first touch of any key.
Briefly press either the + or – key and the set point will be
displayed.
The set point can be increased or reduced in steps of steps of
one unit (e.g. 10 rpm / 1.0 °C) using repeated single presses of
the + or – keys.
Hold down the right hand + key for a time and the set point will
increase continuously or hold down the right hand – key instead
and the set point decreases continuously.
If the door is open, the temperature display will show "OPn".
NOTE:: Entered set points are not validated and confirmation of the input is not necessary.
Don´t forget that the parameter must be switched ON for the control lfunction related to a set
point to be active
The housing of the ECOTRON can be used without the shaker meachanism to provide temperature
control. . For mounting/de-mounting of the shaker mechanism see Chapter 7.8.
6.3 Over-temperature Cut Out
The ECOTRON ® has a temperature "watchdog" to prevent uncontrolled overheating of the
machine. Maximum temperature in normal operation is 65 °C, in case of a malfunction the
temperature is limited to 95 °C.
7. Operation
If the unit is set properly (see chapter 6. 'Putting into Operation") there will not be many alterations
necessary during the ordinary operation of ECOTRON ® apart from the tray loading and unloading.
ECOTRON ® operates without any emissions of any kind apart from the operational sound.
Sudden noise, smell, abnormal strong vibrations and so on are indicators of a problem and have to
be examined immediately.
IN THE EVENT OF SUCH EMISSIONS, TURN OFF AT THE MAINS SWITCH
IMMEDIATELY.
(Operating-Manual_Ecotron _e) page 22 of 53
+
3 7
3 7
3 7
-
x1
°C
+
3 6
3 6
3 6
-
hold
°C
+
2 0
2 0
2 0
-
°C
+
O p n
O p n
O p n
-
°C
