Tally Dascom 2600 Service Manual page 66

Tally Dascom 2600 2610
4.2.5 Print Module Part List for 2610
Part
Item
Number
1 532582 PRINT HEAD CABLE ASSY WIDE
2 532140 PRINT HEAD ASSY
3 532249 RIBBON MASK
4 532144 PAPER GUIDE CARRIAGE
5 532584 PAPER WIDTH SENSOR ASSY
6 535023 HORIZONTAL POSITION SENSOR ASSY
7 532149 PARALLELISM SLEEVE
8 532199 FELT TW43
9 532134 CARRIAGE
10 532210 TENSION SPRING WD0.9 D4.5 L46.45
11 540015 SCREW M3X4 ISO 7045 PHILLIPS
12 532155 BELT TENSIONER SLIDER
13 532120 MATING GEAR ASSY
14 532194 BEARING SEGMENT
15 532188 LEAF SPRING LOWER FRICTION
16 532152 SIDE PLATE LEFT PMC
17 532151 SIDE PLATE RIGHT PMC
18 532147 HEAD GAP SLEEVE
19 540010 E-RING 5.0MM JIS B285
20 540015 SCREW M3X4 ISO 7045 PHILLIPS
21 540020 SCREW M3X6 BH C-TYPE PHILLIPS
22 532060 RIBBON DRIVE ASSY
23 532153 BASE PLATE PMC WIDE
24 532208 PULLEY SHAFT ARRESTOR
25 532121 PULLEY ASSY
26 540001 TIMING BELT MXL T464 W6.4
27 532135 CLAMP CODE STRIPE
28 532139 CODE STRIPE 1/180" WIDE
29 532132 CARRIAGE GUIDE SHAFT D14.0 WIDE
SCREW M3X10 ISO7045 + FW D6.8 T0.5 +
30 540029
SW D5 T0.8
31 532133 RIBBON GUIDE
Description
59
Qty Remark
1
1
1
1
1
1
2
1
1
1
2
1
1
3
3
1
1
2
1
6
3
1
1
1
1
1
1
1
1
2
1
