Tally Dascom 2600 2610
3.2.26 Disassemble the Ribbon Gear Assy
1) Disassemble the Ribbon Gear Assy
Unfasten the 3 fixing screws.→①
Dismount the Ribbon Gear Assy. →②
2) Disassemble the Side Plate Left/Right
Unfasten the 3 fixing screws on the Side Plate Right.→③
Take out the Side Plate Right. →④
Unfasten the 3 fixing screws on the Side Plate Left.→⑤
Take out the Side Plate Left.→⑥
43
