Tally Dascom 2600 2610
3.1.3 Remove the Front Cover
1) Open the Front Cover
2) Remove the Front Cover
Partially open the Front Cover so that you can hold the right edge of it with 4
fingers. Use your thumb to press against the top edge of the Upper Housing and
pull the Front Cover out of the hinge on the Upper Housing.
The Front Cover can only be pulled out from the right first! It requires
some force to pull apart the Front Cover from the Upper Housing. Please
do it carefully in order not to damage a pin holding the flap on left side.
15
