Tally Dascom 2600 2610
4.2.2 Mechanism Assembly Part List for 2610
Part
Item
Number
1 532023 UPPER FRICTION ASSY WIDE
2 532166 CLAMP PRINT BAR
3 532581 PRINT BAR ASSY
4 535000 PAPER END / TOF SENSOR ASSY
5 532169 PAPER GUIDE WIDE
6 532115 GEAR M0.75 T48
7 532106 CAM WHEEL M1.0
8 532107 LEAF SPRING CAM WHEEL
9 532205 LOWER MAIN FRICTION SHAFT ASSY WIDE EPDM
10 532181 SHAFT SQUARE PAPER PATH SELECT WIDE
11 532104 TOOTHED SEGMENT M1.0
12 532019 CHASSIS SIDE PLATE LEFT
13 532020 CHASSIS SIDE PLATE RIGHT
14 532185 COVER TRANSVERSE
15 532080 TRANSVERSE WIDE
16 532170 LOWER SLAVE FRICTION SHAFT ASSY WIDE
17 532180 TENSION SPRING WD0.32 D5.5 L010.0
18 532179 LEVER SWITCH PAPER GUIDE
19 532175 SWITCH PAPER GUIDE 2
20 532174 SWITCH PAPER GUIDE 1
21 532177 SWITCH PAPER GUIDE 4
22 532176 SWITCH PAPER GUIDE 3
23 540010 E-RING 5.0MM JIS B285
24 532178 SHAFT SWITCH PAPER GUIDE WIDE
25 532182 FOOT
26 532187 CLAMP CR- MOTOR
27 532192 MOTOR DAMPER
Description
54
Qty Remark
1
1
1
1
1
2
2
2
1
1
2
1
1
1
1
1
2
2
1
3
1
1
2
1
4
1
1
