Attaching the Cables
Attach drive cables as follows.
drive connector and position the red edge of the cable as shown in
the figures.
Taking care not to bend any pins, press the cable connector firmly
onto the pins.
1.
2.
3.
When connecting cables, align the cable connector with the
Place the drive cage close to the docking station for easy access to the
connectors on the docking station interface board.
Look in the package of cables that came with the docking station and lo-
cate drive power cable.
Connect the power cable to the docking station interface board.
Drive power cable
Adding Options 4-17
