B-14 Pin Assignments
DOCKING EXPANSION PORT ASSIGNMENTS (CONT'D)
Signal
VCR2#
CD2#
GREEN
RED
AGNDV
VEDAT
VECLK
GND
PCTYPE1
DCD
PCTYPE2
TXT
PCTYPE3
DSR
HDDIC
DVSEL0
FDDIC
MOT0
CHRGE
DVSEL1
SCSIIC
MOT1
DSPCI
PDATA0
AUTOFD#
PDATA1
PINIT#
PDATA2
Description
VCR Power On Detect [2]
Docking Detect [2]
CRT Green
CRT Red
Analog GND for Video
VESA Data
VESA Clock
Digital GND
PC Type ID 1
Device Carrier Detect
PC Type ID 2
Transmit Data
PC Type ID 3
Data Set Ready
HDD LED
Drive Select 0
FDD LED
FDD Motor 0
Charge LED
Drive Select 1
SCSI LED
FDD Motor 1
PCI Bus VCC
Printer Data [0]
Printer Auto Feed
Printer Data [1]
Printer Initialize
Printer Data [2]
