Serial Devices

Use the following procedure to connect a serial printer, modem, or any other
RS-232C device to the COM port on the docking station.
Serial devices must have a serial cable with a 9-pin female connector on one
end to connect to your docking station. Other cable requirements depend
upon the device.
tion, make sure the device is set up correctly. Follow the setup in-
structions that come with the option.
1.
2.
3.
4.
5.
5-12 Connecting Peripheral Devices
Before connecting an RS-232C device to your docking sta-
Turn off and unplug the docking station and any external options con-
nected to it.
Make sure that any power to the RS-232C device is off and the power
cable is unplugged.
Connect the RS-232C cable to the serial communication port on the
docking station and to the device.
Use the screws provided to secure the connections.
Connect the power cable to the optional device.
Securing the Cables
