Pin
120
121
122
123
124
125
126
127
128 to 129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
B-12 Pin Assignments
DOCKING EXPANSION PORT ASSIGNMENTS (CONT'D)
Signal
NC
VCR1
CONT
BLUE
GND
AGNDV
OPT2
OPT1
GND
RTS
GND
CTS
DTR
RI
RXD
DSTRK0#
STEP#
HDSEL#
DSWRPRO#
FDIR#
DSDSKC#
DENSY
DSREDA#
WRENB
DSINDEX#
WDATA#
NC
5VDD
Description
Not Used
VCR Power On Detect [1]
VESA Control
CRT Blue
Digital GND
Analog GND for Video
VESA Option [2]
VESA Option [1]
Digital GND
Request to Send
Digital GND
Clear to Send
Data Terminal Ready
Ring Indicator
Receive Data
FDD Track 0
FDD Step
FDD Head Select
FDD Write Protect
FDD Direction
FDD Disk Change
FDD Density
FDD Read Data
FDD Write Enable
FDD Index
FDD Write Data
Not Used
