6. Install the device (see "Installing the 5 1/4-Inch Device").

Installing the 5 1/4-Inch Device

Install an accessible device into the device cage as follows.
1. Remove the 3 1/2-inch drive bracket from the system unit (see "Removing the
3 1/2-Inch Drive Bracket").
2. Remove the front panel (see "Removing the Front Panel").
Follow the preinstallation instructions that come with the device, such as setting
3.
jumpers and switches.
From the front of the system, insert the device, connector end first, into the bay.
4.
Connect the device cables.
5.
6. Align the holes in the device with the holes in the cage.
NOTE: If the device comes with rails, do not
attach them. Remove any rails already attached.
NOTE: To easily access device connectors for
cabling, do not insert a 5 1/4-inch device all the
way into the bay.
Option Installation 3-25
