5-12 Disassembly and Reassembly

ILLUSTRATED PARTS BREAKDOWN

This section contains the illustrated parts breakdown (IPB) and NEC CSD part numbers for
the Direction SP B-Series desktop and minitower computers.
Table 5-2 lists the field-replaceable parts for the desktop and Figure 5-12 provides the
illustrated parts breakdown. Table 5-3 lists the field replaceable parts for the minitower and
Figure 5-13 provides the illustrated parts breakdown.

Table 5-2 Direction SP B-Series Desktop Field-Replaceable Parts List*

Item Description
1 Keyboard, Ergo
2 32x CD-ROM drive
3a Ditto 3200 tape drive, backup
3b Iomega Jazz drive
4 Iomega ATAPI Zip drive
5a 4.3-GB hard drive, IDE UDMA
5b 6.4-GB hard drive, IDE UDMA
5c 8.4-GB hard drive, IDE UDMA
5d 9.1-GB hard drive, IDE UDMA
5e 11.4-GB hard drive, IDE UDMA
5f 14.4-GB hard drive, IDE UDMA
5g 16.8-GB hard drive, IDE UDMA
5h 9.1-GB SCSI hard drive
6 3.5-inch diskette drive
7 Microphone
8 Speaker
9 Left side cover
10 Top cover (access cover)
11 Front panel
12 Right side cover
13 Power supply - Sparkle
14a Altec Lansing speakers, ACS90
14b Altec Lansing speakers, ACS45
____________
* This data was prepared June 1998. For an up-to-date listing of spare parts, please call FaxFlash
1-888-329-0088 (or 1-978-635-6090 outside the U.S.) and order document 42102083.
Part Number
229-00012
730330
320547
221-00018
320703
300856
300857
300858
300833
300851
300849
300850
300689
219-00012
232-00011
158-056684-000
158-056682-000
158-056680-000
158-056678-000
158-056681-000
190300
160312
160314
