2-4 Setup Utility

Legend Bar

Use the keys listed in the legend bar on the bottom of the Setup menu to make the
selections or exit the current menu. Table 2-1 describes the legend keys and their alternates.
Key
F1
Esc
or arrow keys
or arrow keys
Enter

Selecting a Menu Item

To select a menu item, use the up/down arrow keys to move the cursor to the desired field.
Then press . The Exit Saving Changes command in the Exit Menu saves the values
Enter
currently displayed in all the menus.

Displaying a Submenu

To display a submenu, use the up/down arrow keys to move the cursor to the desired
submenu. Then press
submenus.

Getting Help

A Field Help window or Item Specific Help window on the right side of each menu displays
the help text for the currently selected Setup option. It updates as the cursor moves to each
new field.
Pressing F1 on any menu brings up the General Help window that describes the legend keys
and their functions.
Press Esc to exit the current window.

MAIN MENU

This section describes the Main Menu parameters. Other menu parameters are available by
selecting submenus. Use the arrow keys to move the cursor to a parameter and press
to select a submenu. Items with lighter text are not available.

Table 2-1 Setup Key Functions

Function
Provides help for the parameter field being displayed.
Exits the menu.
Selects next menu.
Moves cursor up and down for item selection.
Executes a command or selects submenu.
. A pointer (a right-pointing triangle) marks all selectable
Enter
Enter
