NEC DIRECTION SP B - SERVICE MANUAL 1998 Service Manual page 92

Table 5-3 Direction SP B-Series Minitower Field-Replaceable Parts List*
Item Description
21 Left side cover (access cover)
22 Top cover
23 Right side cover
24 Front panel
25 Speaker
26a 4.3-GB hard drive, IDE UDMA
26b 6.4-GB hard drive, IDE UDMA
26c 8.4-GB hard drive, IDE UDMA
26d 9.1-GB hard drive, IDE UDMA
26e 11.4-GB hard drive, IDE UDMA
26f 14.4-GB hard drive, IDE UDMA
26g 16.8-GB hard drive, IDE UDMA
26h 9.1-GB SCSI hard drive
27 32x CD-ROM drive
28 Iomega ATAPI Zip drive
29 3.5-inch diskette drive
30a Ditto 3200 tape drive, backup
30b Iomega Jazz drive
Parallel printer cable (not shown in figure)
LED and cable, dual color, power (not shown in
figure)
Cable, VMI — DVD PCI board to V330 video
board) (not shown in figure)
Cable, diskette drive, 655 mm, 3 connector (not
shown in figure)
System power switch (not shown in figure)
Phone cable, modem (not shown in figure)
VGA loopback cable (not shown in figure)
PCI video board cable (not shown in figure)
PCI video board (not shown in figure)
Wavetable board (not shown in figure)
Zip drive cartridge (not shown in figure)
Disassembly and Reassembly
Part Number
158-056686-000
158-056685-000
158-056687-000
158-056679-000
158-056684-000
300856
300857
300858
300833
300851
300849
300850
300689
730330
320703
219-00012
320547
221-00018
070829
070834
070805
233-00013
130047
146585
070832
070831
060221
030402
380-00002
5-17
