Fan Assembly Removal; Dimm Module Removal - NEC DIRECTION SP B - SERVICE MANUAL 1998 Service Manual

5-8 Disassembly and Reassembly

Fan Assembly Removal

Remove the fan assembly per the following steps.
Remove the system access cover per Section 3.
1.
At the rear of the system unit, press in on the two locking tabs securing the
2.
assembly to the chassis.
3. Remove the fan by pulling it outward away from the system board.

DIMM Module Removal

Remove any optional DIMM modules from the system board as follows.
1. Remove the system access cover and any expansion boards as previously
described.
Press the locking clips at the ends of the socket away from the DIMM memory
2.
module (see Figure 5-9).
3. Gently rock the module while pulling it up from the socket.
Figure 5-8 Removing the Drive
