[Acc 1]/[Acc 2]; [Remote 1]/[Remote 2]; [Send 1]/[Send 2]; [Alc 1]/[Alc 2] - Icom IC-PW2 Instruction Manual

[ACC 1]/[ACC 2]

Connects to an Icom exciter to input and output control signals for the linear amplifier.
L [ACC 1] corresponds to the exciter connected to [INPUT 1]. [ACC 2] corresponds to the exciter connected to [INPUT 2].
ACC 1/ACC 2 PIN No.
7-pin
7 6
3 1
5 4
2
Rear panel view

[REMOTE 1]/[REMOTE 2]

Connects to an Icom exciter to remotely
control the linear amplifier using CI-V
commands.
L [REMOTE 1] corresponds to the exciter
connected to [INPUT 1].
[REMOTE 2] corresponds to the exciter connected to
[INPUT 2].
NOTE: BE SURE to connect one-to-one with an
Icom exciter.
The amplifier does not support remote control of
multiple units using a CI-V level converter.

[SEND 1]/[SEND 2]

Connects to a non-Icom exciter to
synchronize transmission and reception.
L See pages 2-7 and 2-8 for connecting with a
non-Icom exciter.
L When this connector goes to ground, the amplifier
transmits.
L [SEND 1] corresponds to the exciter connected to [INPUT 1].
[SEND 2] corresponds to the exciter connected to [INPUT 2].

[ALC 1]/[ALC 2]

z Connect to output the ALC voltage to a
non-Icom exciter.
z When an Icom exciter is connected, and
the Digital Pre-Distortion (DPD) function is
used, outputs the feedback signal.
L [ALC 1] corresponds to the exciter connected to [INPUT 1].
[ALC 2] corresponds to the exciter connected to [INPUT 2].
NAME
1 NC No connection.
2 GND Connects to ground.
Input/output pin.
An Icom exciter controls the linear
amplifier.
3 SEND
When transmitting, this pin goes
to ground.
4 NC No connection.
5 ALC ALC voltage output.
6 NC No connection.
7 13.8 V 13.8 V DC input terminal.
I/O
GND
3.5 mm (⅛ in)
SEND
GND
ALC
GND
CONNECTOR INFORMATION
DESCRIPTION

[BAND 1]/[BAND 2]

This terminal is used to control
an external device connected to
[RX-ANT IN] and [RX-ANT OUT],
depending on the voltage of the
selected frequency band.
OUTPUT
PIN No.
BAND
1.8 MHz
1
3.5 MHz
2
7 MHz
3
14 MHz
4
21 MHz
5
28 MHz
6
7
GND
8
NC
L [BAND 1] corresponds to the exciter connected to [INPUT 1].
[BAND 2] corresponds to the exciter connected to [INPUT 2].
L The band voltage is output even if the RF input connector
([INPUT 1]/[INPUT 2]) is set to
L The band voltage output condition can be changed in the
following settings.
» SET > Connectors > Selected BAND
MENU
Output > Output Type (BAND1)
» SET > Connectors > Selected BAND
MENU
Output > Output Type (BAND2)
12-2
SPECIFICATIONS
–
–
Output voltage (TX):
–0.5 V to +0.8 V
Output current: Less than 20 mA
–
Control voltage: –10 to 0 V
–
Input current: Less than 1 A
D-sub 15-pin
..........
8
.........
(
Rear panel view
OUTPUT
PIN No.
BAND
9
NC
#
NC
10 MHz
$
18 MHz
%
24 MHz
&
50 MHz
'
(
NC
(Gray: OFF).
12
1
12
9
