Specifications

D General

• Frequency coverage:

1.800000 ~ 1.999999 MHz

3.500000 ~ 3.999999 MHz

7.000000 ~ 7.300000 MHz

10.100000 ~ 10.150000 MHz

14.000000 ~ 14.350000 MHz

18.068000 ~ 18.168000 MHz

21.000000 ~ 21.450000 MHz

24.890000 ~ 24.990000 MHz

28.000000 ~ 29.700000 MHz

50.000000 ~ 54.000000 MHz

• Usable temperature range:

–10°C ~ +40°C, 14°F ~ 104°F

• Input impedance:

50 Ω (Unbalanced)

• Power supply requirement:

USA/EXP versions

90 ~ 132 V AC (50 Hz/60 Hz),

180 ~ 264 V AC (50 Hz/60 Hz)

EUR version

180 ~ 264 V AC (50 Hz/60 Hz)

• Driving power:

Maximum 100 W

• Maximum output power:

90 ~ 132 V AC: 500 W

180 ~ 264 V AC: 1 kW/500 W

• Spurious emissions:

HF bands:

Less than –60 dB

50 MHz band:

Less than –70 dB

L This value does not apply to unwanted radiation

(excluding harmonics) caused by an exciter.

• Dimensions (projections not included):

425 (W) × 149 (H) × 445 (D) mm,

16.7 (W) × 5.9 (H) × 17.5 (D) in

• Weight (approximate):

21.6 kg, 47.6 lb

D Antenna tuner

• Matching impedance range:

16.7 ~ 150.0 Ω

(HF band to 50 MHz band, and 5 MHz band)

L Only tuning operation is guaranteed in the 5 MHz

band.

• Antenna tuning accuracy:

VSWR 1.5:1 or less

• Automatic tuning time:

Approximately 2 to 3 seconds (general condition)

Maximum 15 seconds

L All stated specifications are subject to change without

notice or obligation.
