7
SET MODE

Network

» SET > Network
MENU
DHCP (Valid after Restart)
Turns the DHCP function ON or OFF.
• OFF: Uses a static IP address.
• ON: Uses the DHCP function.
If a DHCP server is in your network
environment, the IP address is automatically
obtained.
IP Address (Valid after Restart)
Sets the static IP address.
Subnet Mask (Valid after Restart)
(Default: 255.255.255. 0 (24 bit))
Sets the subnet mask to connect to your PC or Local
Area Network (LAN), through the Ethernet.
Default Gateway (Valid after Restart) (Default: . . . .)
Sets the Default Gateway of the IC-PW2.
If you are operating the IC-PW2 using the optional
remote control software*, a default gateway setting is
required.
* Future product, as of June 2024.
Primary DNS Server (Valid after Restart)
Enter the primary DNS server address.
2nd DNS Server (Valid after Restart)
If there are 2 DNS server addresses, enter the
secondary DNS server address.
Network Name
If you are operating the IC-PW2 using the optional
remote control software*, enter a name of up to 15
characters.
* Future product, as of June 2024.
L See page 1-8 for details on entering characters.
(Default: ON)
(Default: 192.168. 0. 10)
(Default: . . . .)
(Default: . . . .)

Display

» SET > Display
MENU
LCD Backlight
Sets the LCD backlight brightness.
LED Bright
Sets the LED brightness.
Meter Response
Sets the meter needle response speed to Slow, Mid,
or Fast.
Meter Peak Hold
Turns the Meter Peak Hold function ON or OFF.
L When the function is turned ON, the indicated value at the
time of the largest swing when using the multi-function
meter is held for 0.5 seconds.
Screen Saver
Sets the Screen Saver function.
L When no operation is performed for the preset period
of time, the screen is automatically turned OFF, and the
indicator on
POWER
To display the screen, push any key or touch the screen.
Opening Message
Selects whether or not to display the opening
message at power ON.
My Call
Displays text as the opening message, up to 10
characters. (p. 8-4)
Temperature Unit
L The default value differs, depending on the linear
amplifier version.
Select the format to display the temperature.
Display Language
Set the screen display language type to English or
Japanese.
L This item is displayed only when the "System Language"
item is set to "Japanese."
7-4
(Default: 50%)
(Default: 80%)
(Default: Mid)
(Default: ON)
(Default: 60min)
blinks blue.
(Default: ON)
(Default: ºF)
(Default: English)
