Unmounting

Before you remove a card when the linear amplifier
is ON, be sure to electrically unmount it, as shown
below.
Otherwise, the data may be corrupted or deleted.
1. Open the SD CARD screen.
» SET > SD Card
MENU
2. Touch "Unmount."
3. Touch [YES] to unmount.
• After unmounting, returns to the SD CARD screen.
L To cancel unmounting, touch [NO].
4. Remove the card from the amplifier.
1 Push in
2 Pull out
L Push in the card until a 'click' sounds to unlock it, and
then pull it out.
5. To close the SD CARD screen, push
When the linear amplifier is OFF
You can remove the card starting from step 4,
described above.

Saving the setting data

The linear amplifier's settings can be saved onto an
SD card.
1. Open the SAVE SETTING screen.
MENU
2. Touch "<<New File>>."
L The file name is automatically set in the following
format: Setyyyymmdd_xx (yyyy: Year, mm: month,
dd: day, xx: serial number).
3. To save the file with the displayed name, touch
[ENT].
L If you want to change the name, delete and reenter it,
and then touch [ENT].
L See page 1-8 for details on entering characters.
4. Touch [YES].
• Saves the data settings.
.
MENU
5. To close the SAVE SETTING screen, push
6-2
» SET > SD Card > Save Setting
6
SD CARD
6
.
MENU
