4
BASIC OPERATION
Changing the status of
[INPUT 1] and [INPUT 2]
You can change the status of [INPUT 1] and [INPUT 2]
by touching the LCD display, or pushing

D Using the RF input selector

z Push
(Indicator lights green: RX side, or
INPUT
is off: OFF) to change to the TX/RX side (Indicator
lights orange).
(Indicator is off) for 1 second to
z Hold down
INPUT
change to the RX side (Indicator lights green).
z Hold down
(Indicator lights orange) for 1
INPUT
second to change the other RF input connector
to the RX side (Indicator lights green) or OFF
(Indicator is off).

D Using the touch screen display

z Touch
(Gray: OFF) or
RX side) to change to
side).
z Touch
(Gray: OFF) for 1 second to change to
(Lights green: RX side).
z Touch
(Lights orange: TX/RX side) for 1
second to toggle the other selector to
green: RX side) or
You cannot change the status of the [INPUT 1] and
[INPUT 2] when:
• [INPUT 1] and [INPUT 2] are controlled by the
external devices that are connected to the [INPUT
1/2] jacks.
• Only 1 exciter is connected.
L When only 1 Icom exciter is connected to [INPUT 1]
and [INPUT 2], the status of [INPUT 1] and [INPUT 2]
will be fixed, as shown below, depending on the
exciter's Split function or Dualwatch function settings.
Icom exciter's setting
Split Dualwatch
function function
OFF OFF
OFF ON
ON OFF
ON ON
.
INPUT
INPUT
Orange: TX/RX side
Green: RX side
Gray: OFF
(Lights green:
(Lights orange: TX/RX
(Lights
(Gray: OFF).
INPUT indicator
INPUT 1 INPUT 2
(MAIN) (SUB)
Orange Gray
Orange Green
Green Orange
Green Orange
Switching the maximum
output power
Touch or
power.

Selecting the frequency band

You can manually select the frequency band.
L When an exciter not supporting CI-V is connected,
manually select the same band as the exciter.
L When "Connect an Exciter to INPUT1 & 2" is selected in
the "Exciter Connection" setting, you cannot change the
frequency band.
1. Touch the frequency band button. (Example: 1.8 MHz)
• The BAND window is displayed.
2. Touch the desired band key. (Example: 14)
L The band in operation is displayed in blue.
• The selected band is displayed. (Example: 14 MHz)
The band in operation
TIP: About the automatic changing of the frequency
band
To automatically follow the frequency band and
frequency of the Icom CI-V exciter, touch "AUTO" in
the BAND window. (p. 3-3)
• "AUTO" and the band of the Icom exciter are displayed
in blue.
L The antenna connectors used in each frequency band
can be saved on the ANTENNA MEMORY screen.
See page 4-4 for details.
4-2
