Touch screen calibration
function
When no screen action occurs, or a different function
is activated after touching the screen, the touched and
detected points may differ.
In that case, the Touch screen calibration function
helps to correct the touch screen sensing accuracy.
1. Open the OTHERS screen.
SET > Others
»
MENU
2. Touch "Touch Screen Calibration."
• A dot appears on the screen.
3. Touch the dot displayed on the screen.
• A new dot appears in another position.
Touch the displayed dot
4. Repeat step 3.
L When the calibration is complete, the linear amplifier
returns to the OTHERS screen.
TIP: When the touch screen is not accurate, and
you cannot access the OTHERS screen.
Do the following steps to display the "Touch Screen
Calibration" screen.
1. Turn OFF the linear amplifier.
2. While holding down
MENU
push to display the "Touch Screen
POWER
Calibration" screen.
3. Repeat steps 3 and 4 in the above column.
4. Touch the frequency band button or a meter
display on the touch screen to confirm that the
touch screen is correctly working.
and ,
QUICK
9-2

Cleaning

DO NOT use harsh solvents such as
benzine or alcohol when cleaning,
because they will damage the linear
amplifier surfaces.
If the linear amplifier becomes dusty or
dirty, wipe it clean with a dry, soft cloth.
9
MAINTENANCE
9
