7
SET MODE

Function

» SET > Function
MENU
Beep Level
Sets the beep output level.
L If the "Beep (Confirmation)" item is set to "OFF," no beep
sounds.
Beep (Confirmation)
Turns the Confirmation beep ON or OFF.
• OFF: Turns OFF the function for silent operation.
• ON: A beep sounds when a switch is pushed, or
the touch screen is touched.
L If "Beep Level" is set to "0," no beep sounds.
<<Tuner Preset Memory Clear>>
Deletes the preset point memorized for fast tuning of
the selected antenna connector.
• Options: ANT1, ANT2, ANT3, ANT4, ANT5, ANT6,
and All
L When touching the option, the confirmation dialog is
displayed.
L To delete all preset points memorized in ANT1 to ANT6,
select "All."
L The preset points cannot be deleted by the Partial reset
or All reset operations. (p. 9-1)
Keyboard Type
Sets the keyboard entry type to Ten-Key or Full
Keyboard.
L You can also select the Full Keyboard or Ten-key by
pushing while displaying an entry mode
QUICK
screen.
Full Keyboard Layout
Selects the on-screen keyboard layout from English,
German, and French.
Screen Capture [POWER] Switch
Assigns the Screen Capture function to
• OFF:
does not act as the Screen Capture
POWER
key.
• ON: The display screen is saved to the inserted
SD card by pushing
Screen Capture File Type
Sets the file format for the Screen Capture function to
PNG or BMP.
(Default: 2)
(Default: ON)
(Default: Full Keyboard)
(Default: English)
(Default: OFF)
.
POWER
.
POWER
(Default: PNG)

Connectors

» SET > Connectors > Selected BAND Output
MENU
Selected BAND Output (BAND 1)
Sets the band voltage output from [BAND 1] to control
an external device (band-pass filter, band decoder,
and so on).
Output Type
Sets the signal line that outputs the band voltage.
• INPUT1: The band voltage on [INPUT 1] is output.
• INPUT2: The band voltage on [INPUT 2] is output.
• TX Side: The band voltage on the TX/RX side
( : Lights orange) is output.
• RX Side: The band voltage on the RX side
( : Lights green) is output.
Output Level
Sets the band voltage output condition.
• ON: Low, OFF: Open:
Sets the terminal of the band to be used to Low
(Shorted) and the terminal of the band not to be
used to Open.
• ON: 12V, OFF: Low:
Sets the terminal of the band to be used to 12 V
(High) and the terminal of the band not to be used
to Low (Shorted).
L When the linear amplifier is in the Antenna Selector
mode, the terminal of the band to be used will be set
to Open.
Selected BAND Output (BAND 2)
Sets the band voltage output from [BAND 2] to control
an external device (band-pass filter, band decoder,
and so on).
Output Type
Sets the signal line that outputs the band voltage.
• INPUT1: The band voltage on [INPUT 1] is output.
• INPUT2: The band voltage on [INPUT 2] is output.
• TX Side: The band voltage on the TX/RX side
( : Lights orange) is output.
• RX Side: The band voltage on the RX side
( : Lights green) is output.
Output Level
Sets the band voltage output condition.
• ON: Low, OFF: Open:
Sets the terminal of the band to be used to Low and
the terminal of the band not to be used to Open.
• ON: 12V, OFF: Low:
Sets the terminal of the band to be used to 12 V
(High) and the terminal of the band not to be used
to Low.
L When the linear amplifier is in the Antenna Selector
mode, the terminal of the band to be used will be set
to Open.
7-2
(Default: INPUT1)
(Default: ON: Low, OFF: Open)
(Default: INPUT2)
(Default: ON: Low, OFF: Open)
